TRACO POWER THL102415WI DC-DC Converter
The Thacopower THL 10-2415WI is a compact 10W DC-DC converter from the THL 10WI series, designed for industrial and communication applications. Encased in a 1" x 1" shielded metal enclosure with an isolated baseplate, it features an ultra-wide input voltage range of 9VDC to 36VDC (nominal 24VDC). The converter provides a fixed output of 24VDC with a maximum output current of 410mA and typical efficiency of 86%. It includes safety features such as remote On/Off control, short circuit, and overvoltage protection, meeting UL/cUL 60950-1 and IEC/EN 60950-1 standards. The device offers an I/O isolation voltage of 1500VDC, an isolation resistance greater than 1000 MΩ at 500VDC, and an I/O capacitance of up to 1200pF. It operates over a temperature range of up to +75°C or +85°C with an optional heatsink. Suitable for instrumentation, distributed power architectures, and industrial electronics, this converter makes it easy to design cost-effective power solutions in compact spaces.
TRACO POWER THL102415WI DC-DC Converter Specifications:
- Power: 10 Watts
- Input Voltage Range: 9VDC to 36VDC
- Output Voltage: 24 VDC
- Max Output Current: 410mA
- Efficiency: 86% (typical)
- Isolation Voltage: 1500 VDC
- Isolation Resistance: >1000 MΩ at 500VDC
- Input/Output Capacitance: up to 1200 pF
- Operating Temperature: up to +75°C or +85°C with heatsink
- Organization: Shielded metal case with isolated baseplate
- Safety Standards: UL/cUL 60950-1, IEC/EN 60950-1
- Protection: Remote On/Off, short circuit, overvoltage
- Power Derating: 2.5%/K above +60°C without heatsink, 3.5%/K with heatsink
- Dimensions: 1" x 1" (25.4 mm x 25.4 mm)
- Soldering Temperature: Max +260°C for 10 seconds
- Weight: 15 g
- Operating Temperature Range: -40°C to +75°C, up to +85°C with heatsink
Buy the Tracopower THL102415WI – Reliable 24VDC Power Converter for Industrial Applications
Enhance your industrial electronics with the Tracopower THL102415WI. This compact 10W DC-DC converter offers an ultra-wide input range, high isolation voltage, and reliable safety features. Its small 1" x 1" footprint makes it ideal for tight spaces in instrumentation, communication, and power architectures. With efficiencies reaching 86%, it ensures energy savings while providing stable output under varying conditions. Designed to operate up to 85°C with optional heatsink, this converter guarantees durability and performance for demanding industrial environments. Purchase online today for reliable, efficient power conversion.
Get Tracopower THL102415WI today—built for precision and long-lasting durability in industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THL102415WI?
You can click on the BUY or RFQ button to purchase THL102415WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL102415WI?
You can download the THL102415WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL102415WI?
TRACO POWER
