TRACO POWER THL102421 DC-DC Converter
The THL 10 series from TracoPower are 10-watt DC/DC converters available in single and dual output configurations. These compact converters are housed in a 1-inch by 1-inch shielded metal case with an isolated baseplate, making them easy to incorporate into various applications. They feature an industrial standard pinout, a wide 2:1 input voltage range, and an input filter that meets EN 55022 class A standards without external components. The models are protected against short circuits and overvoltage, and operate reliably from -40°C to +80°C, with up to +85°C when used with a heat sink. Suitable for instrumentation, distributed power in communication systems, and industrial electronics, these converters provide high efficiency up to 89%. They offer high input-to-output isolation of 1500VDC (60 seconds), an isolation resistance exceeding 1000 MΩ at 500VDC, and a maximum input/output capacitance of 2000 pF. Ripple and noise are minimal, measuring approximately 80mVp-p for 3.3V and 5V models, and around 100mVp-p for other voltage options. The fixed PWM switching frequency is 300kHz. Compliant with UL/cUL 60950-1 and IEC/EN 60950-1 safety standards, these converters come with a 3-year warranty.
TRACO POWER THL102421 DC-DC Converter Specifications:
- Power output: 10 Watts
- Input voltage range: Wide 2:1 ratio (e.g., 9-18 VDC, 18-36 VDC, 36-75 VDC, 48 VDC nominal)
- Output voltage options: 3.3 V, 5.1 V, 12 V, 15 V, +5 V, +12 V, +15 V
- Output current: Ranges from 670 mA to 2500 mA depending on model
- Efficiency: Up to 89%
- Isolation voltage: 1500 VDC (60 sec.)
- Isolation resistance: >1000 MΩ at 500 VDC
- Capacitance: Max 2000 pF input/output capacitance
- Ripple and noise: Approximately 80-100mVp-p
- Operating temperature: -40°C to +80°C, up to +85°C with heat sink
- Switching frequency: 300 kHz fixed
- Protection: Short circuit and overvoltage
- Compliance: UL/cUL 60950-1, IEC/EN 60950-1
- Physical: Metal case, weight approx. 15g, tinned copper pins
- Soldering temperature: Max +260°C for 10 sec.
Buy the TracoPower Series THL 10 Watt DC-DC Converter: THL102421
Enhance your industrial or communication systems with the TracoPower Series THL 10 watt DC-DC converter. Compact and robust, it offers high efficiency up to 89%, reliable protection against short circuits and overvoltage, and an industry-standard pinout for easy integration. With a wide input voltage range from 9V to 75V and operation from -40°C to +85°C when mounted with a heat sink, it ensures dependable power supply in demanding environments. Certified safety standards and a 3-year warranty make it the ideal choice for your power conversion needs.
Order your TracoPower Series THL 10 Watt DC-DC Converter today and give your projects the dependable power they deserve.
