TRACO POWER THL104822WI industrial power converter
The THL 10-4822WI from Tracopower is a 10W DC-DC converter featuring a compact 1" x 1" metal shielded case with an isolated baseplate, ensuring durability in industrial applications. It supports an input voltage range from 18VDC to 75VDC (nominal 48VDC) and provides a stable output of +12VDC at a maximum current of 410mA, with an efficiency of 86%. This converter includes remote on/off, short circuit, and overvoltage protections. It meets UL/cUL 60950-1 standards, supports temperature ranges up to +85°C with heatsink, and is ideal for instrumentation, communication, and industrial electronics, thanks to its wide input range, high EMI filtering, and reliable switching operation.
TRACO POWER THL104822WI industrial power converter Specifications:
- Power: 10 Watts
- Input Voltage Range: 18VDC to 75VDC
- Input Current at no load: 20 mA (48V models)
- Output Voltage: +12VDC
- Output Current Max: 410 mA
- Efficiency: 86% typical
- Isolation Voltage (Input/Output): 1500 VDC
- Operating Temperature: -40°C to +85°C with heatsink
- Switching Frequency: 400 kHz typ.
- Protection: Remote On/Off, short circuit, overvoltage
- EMI Filter: Meets EN 55022 Class A without external components
- Physical: Metal case, 1" x 1" size, weighs 15g
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1
- Soldering Temp: Max +260°C / 10s
- Humidity: Up to 95% rel H, non-condensing
Buy the Tracopower Series THL 10WI DC-DC Converter: THL104822WI
Get the Tracopower THL104822WI 10W industrial power converter online today to ensure reliable and efficient power conversion for your instrumentation, communication, or industrial electronics projects. With its wide input voltage range, UL certification, and high efficiency, this compact converter supports demanding environments up to +85°C with optional heatsinks. Enjoy fast delivery and secure checkout to enhance your project’s power management. Invest in quality power solutions from Tracopower and optimize your industrial applications now.
Buy Tracopower THL104822WI now and experience unmatched reliability and performance in industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THL104822WI?
You can click on the BUY or RFQ button to purchase THL104822WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL104822WI?
You can download the THL104822WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL104822WI?
TRACO POWER
