TRACO POWER THM204823WI Medical Power Converter
The THM 20WI series offers a reliable 20 Watt medical DC/DC converter in a compact 1.6 x 1-inch plastic case, featuring an ultra-wide 4:1 input voltage range. It provides reinforced isolation of 5000 VACrms, extremely low leakage current below 2.5 pA, and high efficiency up to 89%. Suitable for medical and demanding industrial applications, it operates reliably from -40°C to +80°C, with certifications including IEC/EN/ES 60601-1 for 2xMOPP, and compliance to IEC 60601-1-2 EMC standards. Its robust construction ensures performance in high-altitude, temperature-varying, and vibration-prone environments, supported by a 5-year warranty.
TRACO POWER THM204823WI Medical Power Converter Specifications:
- Output Power: 20 W
- Input Voltage Range: 9VDC to 36 VDC / 48 VDC models available
- Output Voltage Options: 5V, 12V, 15V, 24V, +5V/+12V/+15V dual outputs
- Output Current: up to 2000 mA depending on model
- Efficiency: up to 89%
- Isolation Voltage: 5000 VACrms
- Leakage Current: < 2.5 pA
- Operating Temperature Range: -40°C to +80°C
- Altitude: Up to 5000 m
- Vibration and Shock Resistance: According to MIL-STD-810F
- Electromagnetic Compatibility: IEC 60601-1-2, EN55032 Class A
- Dimensions: 25.4mm x 25.4mm x 15mm (1.00 x 1.00 x 0.59 inches)
- Soldering Temperature: Max 265°C for 10s
- Safety Certification: IEC/EN/ES 60601-1 3rd edition, 2xMOPP
- Warranty: 5 Years
Buy the Buy Traco Power Medical Power Supply Part Number THM204823WI Online
Enhance your medical or industrial equipment with the Traco Power THM 20WI series, a 20 Watt power converter featuring reinforced isolation and ultra-wide input range. Engineered for safety and reliability, it complies with IEC 60601-1 standards, offering low leakage current and high efficiency up to 89%. Its compact form factor makes it easy to integrate into various systems, operating flawlessly from -40°C to +80°C. Backed by a 5-year warranty, it ensures continuous, safe operation in demanding environments, making it your ideal power solution for critical applications.
Buy Traco Power THM 20WI series power converter now and experience reliable performance in medical and industrial applications with reinforced isolation.
Frequently Asked Questions
Where can I buy TRACO POWER THM204823WI?
You can click on the BUY or RFQ button to purchase THM204823WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM204823WI?
You can download the THM204823WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM204823WI?
TRACO POWER
