TRACO POWER THN151210N DC/DC Converter
The THN 15N Series is a compact 15 Watt DC/DC converter housed in a shielded 1” x 1” x 0.4” metal package, featuring EN 55032 class A filtering and high efficiency up to 91%. It supports a wide input voltage range of 9-36 VDC with excellent thermal stability from -40°C to +70°C. The model offers precise, isolated output voltages, remote On/Off, and trim functionality. Suitable for mobile electronics, industrial control, communication, and distributed power applications, it ensures reliability with overvoltage, overload, and short-circuit protection, and complies with UL 62368-1 safety standards.
TRACO POWER THN151210N DC/DC Converter Specifications:
- Power Output: 15 Watt
- Input Voltage Range: 9-36 VDC
- Output Voltages: 3.3 V, 5 V, 12 V, 15 V, 24 V with adjustable options 10-20%
- Efficiency: Up to 91%
- Operating Temperature: -40°C to +70°C without derating
- Isolation Voltage: 1600 VDC
- Size: 1” x 1” x 0.4” metal package
- Protection: Overload, Overvoltage, Short circuit
- Remote On/Off: Pin controlled (On open, Off short or 0-1.2 VDC)
- Ripple & Noise: up to 125 mVp-p at 20 MHz bandwidth
- MTBF: 1,670,000 hours
- Switching Frequency: 220-270 kHz
- Certifications: UL 62368-1, EN55032 Class A
- Case Material: Copper, Potting: Silicone, Insulation Resistance: 1 GΩ min.
Buy the Buy Traco Power Series THN 15N Part Number THN151210N Online
Enhance your projects with the Traco Power Series THN 15N 15 Watt DC/DC converter. It offers high efficiency up to 91%, wide input voltage range, and compact metal housing. Features include remote On/Off, precise isolated output voltages, and built-in EN 55032 class A filter, making it suitable for space-constrained industrial, communication, and portable electronics. With robust protection and UL safety certification, this converter ensures durable performance in demanding environments, simplifying integration and delivering reliable, regulated power for your critical applications.
Order your Traco Power Series THN 15N 15 Watt DC/DC Converter today and ensure reliable power conversion for industrial, communication, or embedded systems.
Frequently Asked Questions
Where can I buy TRACO POWER THN151210N?
You can click on the BUY or RFQ button to purchase THN151210N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN151210N?
You can download the THN151210N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN151210N?
TRACO POWER
