TRACO POWER THN302415WI DC-DC Converter Module
The THN 30-2415WI is a high-performance board-mount DC-DC converter delivering 30W power with precise regulation and high efficiency up to 92%. Encased in a compact shielded metal case with isolated baseplate, it supports an ultra-wide 4:1 input voltage range, operating reliably from -40°C to +80°C, with extended capability up to 85°C with a heat-sink. Features include over-temperature protection, adjustable output, 1500VDC input/output isolation, remote On/Off, and no minimum load. Its robust design makes it suitable for space-limited power systems in industrial, communication, and battery-operated applications.
TRACO POWER THN302415WI DC-DC Converter Module Specifications:
- Power Output: 30W
- Input Voltage Range: Ultra-wide 4:1 ratio
- Efficiency: Up to 92%
- Operating Temperature: -40°C to +80°C, up to 85°C with heat-sink
- Isolation Voltage: 1500 VDC
- Adjustable Output Voltage: Yes
- Remote On/Off Control: Yes
- No Minimum Load Required: Yes
- Case Material: Metal with isolated baseplate
- Dimensions: 1.0” x 1.0” x 0.4”
- Protection: Over temperature
- MTBF: 1.2 million hours
- Soldering Temperature Max: 265°C / 10 sec
- Compliance: RoHS 2011/65/EU, UL 60950-1
- Weight: Approximately 16.5 g
Buy the Traco Power THN 302415WI – Reliable DC-DC Converter for Industrial Applications
Purchase the Traco Power THN 302415WI online today and enhance your power systems with this high-performance, compact, and reliable DC-DC converter. Its high efficiency up to 92%, ultra-wide input voltage range, and adjustable output make it ideal for industrial, communication, and battery-operated applications. With robust protection features including over-temperature shutdown and input/output isolation of 1500VDC, this converter ensures safe and stable operation in a variety of environments. Secure your supply chain now for dependable power management.
Buy Traco Power THN 302415WI now and experience unmatched reliability and high efficiency suitable for space-constrained power electronics.
Frequently Asked Questions
Where can I buy TRACO POWER THN302415WI?
You can click on the BUY or RFQ button to purchase THN302415WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN302415WI?
You can download the THN302415WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN302415WI?
TRACO POWER
