TRACO POWER TEN62415WIN Industrial Power Converter
The Power Ten 6WIN Series offers 6-watt isolated DC/DC converters designed for industrial applications requiring reliable power with minimal external components. These converters operate efficiently across a wide temperature range from -40°C to +85°C and feature no minimum load requirements. They include options with 1500 VDC and 3000 VDC functional insulation, ensuring safety and durability. Encased in a compact DIP-24 plastic package, they meet EN 55022 class A standards, making them ideal for cost-sensitive, space-constrained environments with high efficiency and overload protection.
TRACO POWER TEN62415WIN Industrial Power Converter Specifications:
- Input voltage range: 9-36 VDC or 18-75 VDC depending on model
- Output voltage options: 3.3 V, 5 V, 12 V, 15 V, 24 V with respective current ratings
- Isolation voltage: 1500 VDC or 3000 VDC (models with suffix -HI)
- Efficiency: 77% to 84% depending on model
- Operating temperature: -40°C to +85°C
- No minimum load required
- Input current at full load: 150-300 mA depending on model and input voltage
- Surge voltage: 50 V (24 V models), 100 V (48 V models)
- Ripple and noise: max 80 mVp-p at 20 MHz bandwidth
- Switching frequency: approx. 330 kHz
- Case temperature max: +100°C; weight: 180 g
- Certifications: UL, CSA, IEC, EN 60950-1
- Soldering temperature: max 260°C (10 sec.)
Buy the Buy TracoPower DC/DC Converters Part Number TEN62415WIN Online
Purchase the TracoPower TEN62415WIN DC/DC converter online today and benefit from a highly reliable, efficient power module suitable for various industrial, automation, and control applications. This 6-watt converter features wide temperature operation, high insulation voltage, and no minimum load requirement, simplifying design integration. Its compact DIP-24 package ensures easy installation in space-constrained environments. With decades of engineering expertise, TracoPower ensures durability, safety, and compliance with global standards. Order now for quick delivery and seamless performance in your critical projects.
Buy TracoPower TEN62415WIN now and experience unmatched reliability and high efficiency in industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TEN62415WIN?
You can click on the BUY or RFQ button to purchase TEN62415WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN62415WIN?
You can download the TEN62415WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN62415WIN?
TRACO POWER
