TRACO POWER THN304815WI Power Converter
The THN 30WI series is a compact 30-watt DC/DC converter module designed for space-constrained electronic systems. It features a shielded metal case with an isolated baseplate, an ultra-wide 4:1 input voltage range, and high efficiency up to 92%. Suitable for industrial, communication, and mobile electronics, it operates from -40°C to +80°C, with derating up to +85°C with a heatsink. The series provides adjustable output voltage, remote On/Off control, and robust safety and isolation features, making it an ideal power solution for demanding applications.
TRACO POWER THN304815WI Power Converter Specifications:
- Power Output: 30W
- Dimensions: 1.0” x 1.0” x 0.4”
- Input Voltage Range: 4:1 ultrawide, models vary from 9V to 75V
- Output Voltage: adjustable ±10-20%, models available include 3.3V, 5V, 12V, 15V, 24V
- Efficiency: up to 92%
- Operating Temperature: -40°C to +80°C, derating to +85°C with heatsink
- Isolation Voltage: 1500 VDC
- Input Current at No Load: 10mA (24V), 8mA (48V)
- Start-up Voltage: <90VDC (24V), <18VDC (48V)
- Over/Under Voltage Protection: Yes
- Ripple & Noise: 75mVp-p (varies by model), measured with specified capacitors
- MTBF: 337,000 hours
- Switching Frequency: ~275 kHz to 330 kHz
- Soldering Temperature: Max 265°C / 10 sec
- Safety Standards: UL, IEC/EN 60950-1, RoHS compliant
- Weight: 16.5g
Buy the TracoPower Series THN 30WI DC/DC Converter: THN 30WI Series 30 Watt
Purchase the TracoPower Series THN 30WI high-performance 30-watt DC/DC converter online today. Perfect for demanding industrial, communication, and mobile equipment applications. Its compact size, high efficiency up to 92%, adjustable output, and excellent isolation make it ideal for space-limited projects. With a broad operating temperature range from -40°C to +80°C and derating up to +85°C with a heatsink, this converter ensures reliable power delivery under harsh conditions. Easy remote On/Off control and safety compliance add to its value for professional electronics systems.
Order your TracoPower Series THN 30WI 30 Watt high efficiency DC/DC converter today and ensure reliable power in space-constrained industrial and communication systems.
Frequently Asked Questions
Where can I buy TRACO POWER THN304815WI?
You can click on the BUY or RFQ button to purchase THN304815WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN304815WI?
You can download the THN304815WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN304815WI?
TRACO POWER
