TRACO POWER TIM21215SM Medical Power Converter
The TIM 2SM series are compact 2 Watt DC/DC converters designed for medical applications, offering reinforced isolation of 5000 VACrms, low leakage current under 2 pA, and an extended temperature range from -40°C to 95°C. These certified converters comply with IEC/EN/ES 60601-1 for 2XMOPP and operate at altitudes up to 5000 meters. Suitable for insulation of electrical equipment from patient-contact parts, they feature low conducted noise, EMC compliance, and built-in safety protections, making them ideal for medical and industrial applications requiring reliable, high-performance power conversion.
TRACO POWER TIM21215SM Medical Power Converter Specifications:
- Power: 2 Watt
- Isolation Voltage: 5000 VACrms (reinforced insulation)
- Working Voltage: 250 VAC
- Leakage Current: < 2 pA
- Temperature Range: -40°C to 95°C
- Efficiency: Up to 81%
- Output Power Max.: 2W
- Output Voltage Options: 3.3 VDC, 5 VDC, 9 VDC, 12 VDC, 15 VDC, 24 VDC, 36 VDC, 48 VDC
- Input Voltage Range: varies per model, e.g., 3.3V to 48V
- Start-up Voltage: 4.5 VDC to 36 VDC depending on model
- Ripple & Noise: 50 mVp-p typical
- MTBF: 6,809,000 hours
- Dimensions: approx. 23 x 15 mm
- Operating Humidity: 5% to 95% RH non-condensing
- Case Material: Non-conductive black plastic
- Compliance: IEC/EN/ES 60601-1, IEC 60601-1-2, RoHS
- Protection: Overvoltage, short circuit, automatic recovery
- Isolation Capacitance: 20 pF max.
- Altitude: Up to 5000 m
- Switching Frequency: 100 kHz
Buy the Traco Power TIM 21215SM – Reliable Medical Power Supply for Industrial Applications
Experience the high reliability of the Traco Power TIM 21215SM, a 2 Watt medical power converter offering reinforced 5000 VACrms isolation, low leakage current, and extensive safety features. Designed for medical devices, it ensures safety compliance under IEC/EN standards and operates efficiently over wide temperature ranges. With its compact SMD package, it is easy to integrate into diverse systems, providing stable voltage regulation, low noise, and high efficiency. Trust this certified power module for safe, reliable performance in sensitive healthcare and industrial environments.
Get Traco Power TIM 21215SM today—built for medical-grade insulation and long-lasting durability.
Frequently Asked Questions
Where can I buy TRACO POWER TIM21215SM?
You can click on the BUY or RFQ button to purchase TIM21215SM from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TIM21215SM?
You can download the TIM21215SM datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TIM21215SM?
TRACO POWER
