TRACO POWER TIM351223SM Medical Power Converter
The TIM 3.5SM series is a compact 3.5 Watt DC/DC converter line designed for medical applications, featuring reinforced isolation of 5000 VACrms, low leakage current under 2 pA, and compliance with IEC 60601-1 standards. These converters are suitable for insulation of electrical equipment from patient-connected parts, operate within a wide temperature range from -40°C to 90°C, and support various input voltages with efficiencies up to 83%. They meet EMC standards including IEC 60601-1-2 4th edition, providing highly reliable performance in medical environments with excellent safety and immunity features.
TRACO POWER TIM351223SM Medical Power Converter Specifications:
- Power: 3.5 Watt
- Isolation Voltage: 5000 VAC (reinforced insulation)
- Operating Temperature: -40°C to 90°C, derating 3.3%/K above 75°C
- Input Voltage Range: 4.5 - 36 VDC (models vary)
- Output Voltage: 4.5 V to 24 V (various models)
- Output Current: 117 mA to 700 mA (depending on model)
- Efficiency: up to 83%
- Leakage Current: Less than 2 pA at 240 VAC
- Start-up Voltage: 4.5 VDC to 36 VDC
- Shock & Vibration Resistance: according to MIL-STD-810F
- EMC Compliance: IEC 60601-1-2 4th edition, EN55032 class A
- Dimensions: Compact SMD package
- Weight: Approximately 7 grams
- Certification: IEC/EN/ES 60601-1 3rd edition, ISO 14971 risk management
- Isolation Capacitance: 20 pF max.
- Casing: Non-conductive black plastic, potting with UL94 V-0 silicone
- Humidity: 5% to 95% rel H max.
- MTBF: 5,041,000 hours
- Safety Standards: ANSI/AAMI ES60601-1, IEC/EN60601-1 3rd edition
Buy the Buy Traco Power TIM 3.5SM Part Number TIM351223SM Online
Experience the dependable performance of the Traco Power TIM 3.5SM medical power converter. With reinforced isolation of 5000 VAC, ultra-low leakage current, and compliance with IEC 60601-1 standards, it is ideal for ensuring patient safety and equipment protection. Its wide temperature operation from -40°C to 90°C and high efficiency up to 83% guarantee reliable support for medical devices. Buy online today for quick delivery and trusted quality in your healthcare solutions.
Buy Traco Power TIM 3.5SM now and ensure reliable, medical-grade electrical insulation with high safety standards and excellent performance.
Frequently Asked Questions
Where can I buy TRACO POWER TIM351223SM?
You can click on the BUY or RFQ button to purchase TIM351223SM from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TIM351223SM?
You can download the TIM351223SM datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TIM351223SM?
TRACO POWER
