TRACO POWER TME2409S DC/DC Converter
The TME series offers compact, 1-watt isolated DC/DC converters in a SIP package, requiring only 0.7 cm2 of board space. They feature industry-standard pinout, 1000 VDC isolation, efficiencies up to 80%, and operate within -40°C to +85°C temperature range. Ideal for generating isolated voltages in space-constrained applications, these high-reliability converters undergo full burn-in and are ROHS compliant. Suitable for industrial, automation, and power supply projects, they provide a dependable power conversion solution with various voltage options.
TRACO POWER TME2409S DC/DC Converter Specifications:
- Input Voltage: 3.3 V, 5 V, 12 V, 24 V models
- Output Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V options
- Output Current Max.: 80-260 mA depending on model
- Efficiency: Up to 80%
- Isolation Voltage: 1000 VDC
- Operating Temperature: -40°C to +85°C
- Ripple and Noise: 150 mV pk-pk at 20 MHz bandwidth
- Short Circuit Protection: Limited 1 sec.
- Dimensions: 0.7 cm² board space, case temperature max +95°C
- Material: Non-conductive black plastic (UL 94V-0)
- Surge Voltage: 3.3 V models 6 V max, 5 V models 9 V, 12 V models 18 V, 24 V models 30 V max
- MTTF: Greater than 2,000,000 hours
- Soldering Temperature: Max. 265°C for 10 sec.
Buy the TracoPower TME2409S – Reliable Power Conversion for Industrial Applications
Purchase the TracoPower TME2409S online today to secure a compact, high-efficiency, and reliable 1-watt isolated DC/DC converter. Perfect for tight spaces, this converter offers industry-standard pinout, 1000 VDC isolation, and operates reliably from -40°C to +85°C. Its ROHS compliance ensures environmentally friendly production. With full burn-in testing and a robust design, TME2409S is ideal for industrial automation, medical equipment, and power supply applications. Buy now to enhance your system’s power reliability and performance with this high-quality, cost-effective converter.
Order your TracoSeriesTME2409S 1 Watt DC/DC converter today and ensure your projects benefit from dependable, space-efficient power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TME2409S?
You can click on the BUY or RFQ button to purchase TME2409S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME2409S?
You can download the TME2409S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME2409S?
TRACO POWER
