TRACO POWER TES11211 DC/DC Converter
The TES 1 Series from Traco Power offers compact 1 Watt DC/DC converters designed for isolated voltage applications in digital interfaces and distributed power systems. These high-efficiency, unregulated converters feature a small SMD package, operating temperatures from -40°C to +90°C, and are qualified for lead-free reflow soldering. They support input voltages of 5, 12, and 24 VDC with outputs ranging from 3.3 V to 15 V, making them ideal for noise reduction, ground loop elimination, and voltage conversion in space-constrained electronic systems. Packaged in tape and reel, they meet RoHS and Reach standards, ensuring reliability in various environments.
TRACO POWER TES11211 DC/DC Converter Specifications:
- Input Voltage: 5, 12, 24 VDC
- Output Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V
- Max Output Current: 435 mA
- Efficiency: up to 80%
- Isolation Voltage: 1500 VDC for 60 seconds
- Operating Temperature: -40°C to +90°C
- Case Material: UL94V-0 rated plastic
- Weight: Single output models 1.7 g, dual output 2.0 g
- Qualification: RoHS, Reach, lead-free reflow solder process
- Peak Package Temperature: 245°C
- Humidity: Up to 95% non-condensing
- MTBF: Over 2 million hours
Buy the Traco Power Series TES Power Converters: TES 1 Series 1 Watt
Discover the Traco Power TES 1 Series 1 Watt DC/DC converters, engineered for exceptional efficiency and reliable voltage isolation in compact applications. These converters support input voltages of 5, 12, and 24 VDC with multiple output options, making them ideal for noise reduction, ground loop elimination, and voltage conversion in digital and industrial systems. Designed with a small SMD package, they are qualified for lead-free reflow soldering and operate over a temperature range of -40°C to +90°C. Purchase online today for trusted power solutions with a 3-year warranty, RoHS, and Reach compliance.
Buy Traco Power TES 1 Series 1 Watt DC/DC converters now and experience unmatched reliability and high efficiency for space-constrained power applications.
