TRACO POWER TMR11211SM DC/DC Converter Module
The TMR 1SM series are compact 1-watt isolated DC/DC converter modules with regulated outputs and wide input voltage range. They come in SIP-6 or SMD packages, occupying only 0.2 square inches of PCB space. Designed for high efficiency and operation from -40°C to +85°C, these converters feature remote On/Off control, short circuit protection, and are suitable for communication, industrial electronics, and instrumentation. Their reliable, cost-effective design makes them an excellent choice for space-constrained applications requiring stable power conversion and galvanic isolation up to 1500 VDC.
TRACO POWER TMR11211SM DC/DC Converter Module Specifications:
- Input Voltage Range: 4.5 - 9.0 VDC or 5 VDC with start-up at 4.5 VDC and undervoltage lockout at 4 VDC
- Output Voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC, or 36-75 VDC depending on model
- Output Current: 42 mA to 200 mA depending on model
- Efficiency: up to 82%
- Isolation Voltage: 1500 VDC for 60 seconds
- Ripple and Noise: 50 mVp-p for SIP models, 30 mVp-p for SMD models
- Operating Temperature Range: -40°C to +85°C
- Dimensions: SIP package approximately 0.5 x 0.5 inches (12.7 x 12.7 mm), SMD package similar footprint
- Switching Frequency: 220 kHz
- Safety Standards: UL 60950-1, IEC/EN 60950-1, CB certified
- 耐热、绝缘与抗干扰设计，适用于空间有限的工业电子设备
Buy the TracoPower TMR11211SM – Reliable Industrial Power Supply Modules for Electronic Equipment
Order the TracoPower TMR11211SM DC/DC converter module online today to ensure a compact, reliable power solution for industrial, communication, and instrumentation applications. Designed with a regulated output, wide input voltage range, and high efficiency, this module offers exceptional stability and protection features like short circuit prevention. Its small footprint and robust performance make it ideal for space-constrained environments, providing long-lasting, dependable power supply in demanding conditions. Shop now for quick delivery and enhanced power management for your project.
Get TracoPower TMR11211SM today—built for space-efficient industrial electronics with regulated outputs and high efficiency.
Frequently Asked Questions
Where can I buy TRACO POWER TMR11211SM?
You can click on the BUY or RFQ button to purchase TMR11211SM from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR11211SM?
You can download the TMR11211SM datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR11211SM?
TRACO POWER
