TRACO POWER TMR12413SM DC/DC Converter Module
The TMR12413SM series is a compact 1-Watt isolated DC/DC converter module designed for efficient power conversion in communication equipment, instrumentation, and industrial electronics. It features a wide 2:1 input voltage range, regulated output, remote On/Off control (SMD), and continuous short circuit protection, ensuring reliable performance across -40°C to +85°C. Its small footprint and cost-optimized design make it ideal for space-constrained applications, providing high efficiency, safety isolation of 1500 VDC, and robust operation suitable for diverse industrial environments.
TRACO POWER TMR12413SM DC/DC Converter Module Specifications:
- Input voltage range: 4.5 - 9.0 VDC, 5.0 V, 12 V, 24 V, 48 V models available
- Output voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC, 36-75 VDC models
- Maximum output current: 200 mA (varies by model)
- Input/output isolation: 1500 VDC, 50 pF capacitance, >1 GOhm resistance
- Operating temperature: -40°C to +85°C, derating above 75°C for SMD models
- Efficiency: 76% to 82%, depending on model
- Mechanical: SIP-6 or SMD package, weight approx. 3.1-3.3 grams
- Switching frequency: 220 kHz, safety standards compliance with UL, IEC and EN certifications
- Short circuit protection: continuous, automatic recovery
- Remote On/Off control: SMD models, ON: <0.6 VDC, OFF: 2.7-15 VDC
Buy the Traco Power Series TMR 1SM DC/DC Converter: TMR12413SM
Purchase the Traco Power TMR12413SM today, an efficient 1-Watt isolated power converter designed for reliable operation across wide temperature ranges. Its compact size, regulated output, remote On/Off, and short circuit protection make it an ideal choice for demanding communication, instrumentation, and industrial applications. With high efficiency and robust safety standards, this converter ensures consistent performance and easy integration into space-constrained systems. Order now to experience quality and durability for your power management needs.
Get Traco Power TMR12413SM today—built for reliable power isolation and space-efficient design in industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TMR12413SM?
You can click on the BUY or RFQ button to purchase TMR12413SM from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR12413SM?
You can download the TMR12413SM datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR12413SM?
TRACO POWER
