TRACO POWER TMR2422 DC/DC Converter Module
The TMR-2 series offers a compact, highly efficient 2W isolated DC/DC converter module designed for space-constrained applications such as communication, industrial electronics, and instrumentation. It features a wide 2:1 input voltage range, full SMD design, remote On/Off control, and abundant protections including short-circuit and thermal shutdown. Operating seamlessly from -40°C to +85°C, it ensures reliable performance with an ultra-small footprint of just 2.0 cm². Suitable for demanding environments, this module integrates excellent load and line regulation, making it ideal for many industrial power supply needs.
TRACO POWER TMR2422 DC/DC Converter Module Specifications:
- Input voltage range: 5 VDC to 48 VDC (various models)
- Output voltage options: 5 VDC, 12 VDC, 15 VDC, 3.3 VDC, 9-36 VDC
- Maximum output current: 200 mA to 500 mA depending on model
- Efficiency: up to 84%
- Input current at full load: 62 mA to 645 mA depending on input voltage
- Input surge voltage: 15 V to 100 V max. (depending on model)
- Isolation voltage: 1600 VDC
- Operating temperature: -40°C to +85°C
- Protection: Short circuit, thermal, and overload protection
- Dimensions: 21.8 mm x 10.3 mm x 11 mm (approximate), 2.0 cm² footprint
- Weight: 48 g
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, RoHS compliant
- Isolation capacitance: 200 pF
- Isolation resistance: >1 GOhm
- Switching frequency: 100-650 kHz
- Remote On/Off control: open/high impedance or via 1kΩ resistor
Buy the TracoPower TMR2422 – Reliable DC-DC Converter for Industrial Applications
Enhance your industrial power management with the TracoPower TMR2422 DC/DC converter module. Designed for compact spaces, it offers high efficiency, wide 2:1 input range, and robust protections including short-circuit and thermal shutdown. Operating from -40°C to +85°C, this module is perfect for communication, automation, and industrial electronics requiring reliable power. Its small footprint of just 2.0 cm² allows seamless integration into tight spaces. Purchase online today to ensure your systems operate smoothly with proven quality and performance.
Buy TracoPower TMR2422 now and experience unmatched reliability and performance in space-saving power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TMR2422?
You can click on the BUY or RFQ button to purchase TMR2422 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR2422?
You can download the TMR2422 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR2422?
TRACO POWER
