TRACO POWER TMV0505D Miniature DC/DC Converter
The TMV series are miniaturized, isolated 1 W DC/DC converters designed for space-critical applications. Featuring high isolation of 3000 VDC, unregulated high efficiency up to 81%, and a single-in-line package, these converters support extended temperature ranges from -40°C to +85°C or +90°C depending on model. They are pin-compatible with competitors, RoHS compliant, and suitable for board level power distribution, offering optimal performance in industrial and automation systems with minimal footprint. SMD technology ensures cost-effective manufacturing.
TRACO POWER TMV0505D Miniature DC/DC Converter Specifications:
- Input Voltage Range: 5 VDC, 9 VDC, 12 VDC, 15 VDC, 24 VDC models
- Output Voltage: 5 VDC, 9 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Current: 67 mA to 200 mA depending on model
- Isolation Voltage: 3000 VDC
- Efficiency: Up to 81%
- Operating Temperature: -40°C to +85°C / +90°C depending on model
- Storage Temperature: -50°C to +125°C
- Humidity: 95% non-condensing
- Case Material: Non-conductive UL 94V-0 plastic
- Dimensions: Approximately 17.8 mm x 7.62 mm x 10.2 mm (0.7 in x 0.3 in x 0.4 in)
- Soldering Temperature: max 265°C / 10 seconds
- Isolation Resistance: >10 GOhm
- Insulation Capacitance: 60 pF typical
- Ripple & Noise: 65 mVp-p typical, 100 mVp-p max
- MTBF: Over 2 million hours
- Certification: RoHS compliant, UL Listed
- Switching Frequency: 70 to 120 kHz
- Weight: 2.1 g to 2.6 g depending on model
Buy the TRACO TMV0505D – Reliable 1 W DC/DC Converter for Industrial Applications
Order the TRACO TMV0505D online today to ensure your industrial projects benefit from a high-performance, compact, and reliable 1 W DC/DC converter. With high isolation up to 3000 VDC, efficiency up to 81%, and an extended temperature range from -40°C to +85°C, this converter is perfect for space-critical applications. Its RoHS compliance and simple pin configuration make installation straightforward. Enhance your system’s power management today by purchasing this tested, reliable converter online and experience optimal performance and peace of mind.
Buy TRACO TMV0505D now and enjoy high efficiency, high isolation, and compact design ideal for industrial and automation systems.
Frequently Asked Questions
Where can I buy TRACO POWER TMV0505D?
You can click on the BUY or RFQ button to purchase TMV0505D from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMV0505D?
You can download the TMV0505D datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMV0505D?
TRACO POWER
