TRACO POWER TMR94813WI DC-DC Converter
The TMR 9-4813WI from TracoPower is a high-density, 9W, isolated, and regulated DC-DC converter with a single output. It features an 8-pin SIP package and a wide input voltage range of 18VDC to 75VDC. The converter offers an output voltage of 15VDC with a maximum current of 600mA and an efficiency of 88%. With a compact size of 9.6mm x 11.2mm x 21.8mm, it is suitable for space-critical applications. The device includes remote on/off control, indefinite short circuit protection, and no minimum load requirements. It provides robust features such as input voltage surge handling up to 100V, I/O isolation of 1500VDC for 60 seconds, and excellent electromagnetic compatibility with EN 55022 Class A compliance. The converter is protected against ESD with air and contact discharge ratings and is housed in a copper casing with UL 94V-0 rated silicone potting. Its operating temperature range spans from -40°C to 85°C. Approved under UL 60950-1 and IEC/EN 60950-1 standards, it is ideal for use in communication equipment and instrumentation requiring reliable power management in compact form factors.
TRACO POWER TMR94813WI DC-DC Converter Specifications:
- Input Voltage Range: 18VDC to 75VDC
- Output Voltage: 15VDC
- Output Current Max: 600mA
- Efficiency: 88%
- Isolation Voltage: 1500VDC for 60 seconds
- Isolation Capacitance: 50 pF
- Isolation Resistance: >1 GOhm
- Operating Temperature Range: -40°C to +85°C
- Size: 9.6mm x 11.2mm x 21.8mm
- Case Material: Copper with UL 94V-0 silicone potting
- Surge Voltage: up to 100V
- EMC Compatibility: EN 55022 Class A
- ESD Protection: Air +8kV, Contact +6kV
- Regulation: ±0.2% (input), 1.0% (load)
- Ripple & Noise: 75 mVpk-pk
- Short Circuit Protection: Indefinite, automatic recovery
- Efficiency: up to 88%
- Compliance: UL 60950-1, IEC/EN 60950-1
- Protection: Remote On/Off, no minimum load required
Buy the TracoPower TMR94813WI – Reliable DC-DC Converters for Industrial Applications
Purchase the TracoPower TMR94813WI DC-DC converter online today to benefit from its compact size, high efficiency, and robust features like remote on/off and short circuit protection. Designed for industrial applications, this 9W isolated power module offers a wide input range of 18VDC to 75VDC, delivering a regulated 15VDC output at 600mA. Its excellent electromagnetic compatibility and UL 60950-1 certification make it suitable for communication equipment and instrumentation in space-constrained environments. Secure your reliable power solution now and optimize your electronic systems with precision and safety.
Order your TracoPower TMR94813WI high-efficiency DC-DC converter today and ensure reliable power in your space-critical communication and instrumentation projects.
Frequently Asked Questions
Where can I buy TRACO POWER TMR94813WI?
You can click on the BUY or RFQ button to purchase TMR94813WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR94813WI?
You can download the TMR94813WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR94813WI?
TRACO POWER
