TRACO POWER TPP15105AJ Medical Power Supply
The TPP 15A-J series provides 15-watt, open-frame medical power supplies designed for high reliability and safety in medical environments. Certified to IEC/EN/ES 60601-1 3rd edition with 2 x MOPP, these units feature reinforced double I/0 isolation, low leakage current below 75 µA, and high efficiency up to 89%. They operate up to 5000 meters altitude and cover a temperature range from -40°C to +60°C, with optional derating up to 85°C at 50% load. Designed to comply with EMC standards IEC 60601-1-2 4th edition, ensuring medical-grade immunity and emission standards are met.
TRACO POWER TPP15105AJ Medical Power Supply Specifications:
- Power Output: 15 W
- Output Voltage Options: 3.3 VDC (4,000 mA), 5 VDC (3,000 mA), 9 VDC (1,670 mA), 12 VDC (1,260 mA), 15 VDC (11,000 mA), 24 VDC (625 mA), 36 VDC (417 mA), 48 VDC (313 mA)
- Input Voltage Range: 85 - 264 VAC, 120 - 370 VDC (designed for, no certification)
- Input Frequency: 47 – 63 Hz
- Efficiency: Up to 89%
- Operating Temperature: -40°C to +60°C, derating to 85°C at 50% load
- Altitude: Up to 5000 m
- Leakage Current: <75 µA
- Isolation Test Voltage: 5,657 VDC input to output; 21,121 VDC input to case; 21,121 VDC output to case
- Protection: Continuous, automatic recovery short circuit; Overvoltage protection 126-140% of Vout
- Safety Standards: IEC 60601-1, IEC 62368-1, UL 62368-1
- EMC Compliance: IEC 60601-1-2 4th edition, EN 55011, EN 55032, FCC Part 15
- Dimensions: 1.0” x 2.6” (approximate)
- Weight: 199 grams
- Connections: JST series connectors, compatible with crimp terminals SVH-21T-P1.4 and SVH-21T-P1.1
Buy the Traco Power TPP-15A-J – Reliable Medical Power Supply for Industrial Applications
Purchase the Traco Power TPP 15A-J series online now and benefit from certified medical-grade safety, reinforced isolation, and high efficiency. Ideal for medical devices requiring low leakage current and operation up to 5000 meters altitude. With a compact design, various output voltages, and compliance with IEC 60601-1 standards, this power supply guarantees dependable performance in critical applications. Enjoy fast delivery, trusted quality, and strategic support—order today to enhance your medical and industrial systems with confidence.
Order your Traco Power TPP 15A-J series 15W medical power supply today and ensure reliable performance for your medical or industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER TPP15105AJ?
You can click on the BUY or RFQ button to purchase TPP15105AJ from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP15105AJ?
You can download the TPP15105AJ datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP15105AJ?
TRACO POWER
