TRACO POWER TMR34815WIR DC/DC Converter
The TMR 3WIR series comprises compact 3 Watt DC/DC converters housed in a durable SIP-8 metal case, designed for space-efficient applications. With an input voltage range of 9-36V or 43-160V DC and high efficiency up to 83%, these fully regulated, isolation-rated devices include features like remote On/Off, short circuit protection, and are compliant with EN 50155 railway standards. Operating from -40°C to +90°C and rated for a 3,000VDC isolation voltage, they are suitable for railway, industrial, and automation applications requiring reliable power conversion in harsh environments.
TRACO POWER TMR34815WIR DC/DC Converter Specifications:
- Input Voltage Range: 9-36V/DC or 43-160V/DC
- Output Voltage Options: 3.3V, 5V, 9V, 15V, 24V, 12V, 15V, 48V nominal, with various current ratings
- Maximum Output Current: 700 mA to 300 mA depending on model
- Efficiency: Up to 83%
- Operating Temperature: -40°C to +90°C with derating above 78°C
- Isolation Voltage: 3000VDC input to output, 1500VDC input/output to case
- Dimensions: Compact SIP-8 metal case, approximately 19.8 mm x 9.0 mm x 12.7 mm
- Ripple & Noise: Up to 75 mVp-p
- Surge Voltage (1.5x): 50V to 185V max
- Short Circuit Protection: Yes, automatic recovery
- Remote On/Off: Yes, controlled via 2-4 mA current
- Mounting: Through-hole with copper casing, UL94 V-0 rated silicone potting
- Certifications: EN 50155 railway, UL 60950-1, IEC/EN/UL 60950-1 compliance
- MTBF: Approximately 5,535,000 hours
Buy the Buy Traco Power TMR Series Part Number 34815WIR Online
Order the Traco Power TMR 34815WIR DC/DC converter online today for reliable performance in demanding industrial and railway applications. Compact and robust, it offers wide input voltage compatibility, excellent efficiency, and safety certifications ensuring durability and safety in harsh environments. Perfect for space-critical projects requiring high reliability, the TMR 34815WIR features automatic short circuit protection, remote On/Off capability, and extensive isolation up to 3,000VDC. Enjoy fast delivery, trusted quality, and technical support by purchasing this dependable power conversion solution now.
Get Traco Power TMR 34815WIR today—built for railway and industrial environments with robust safety and reliability features.
Frequently Asked Questions
Where can I buy TRACO POWER TMR34815WIR?
You can click on the BUY or RFQ button to purchase TMR34815WIR from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR34815WIR?
You can download the TMR34815WIR datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR34815WIR?
TRACO POWER
