TRACO POWER TRI61211 DC/DC Converter
The TRI 6 Series is a compact, high-isolation 6 Watt DC/DC converter designed for demanding industrial, transportation, and instrumentation applications. It features reinforced insulation capable of withstanding test voltages up to 9000 VDC for 1s and working voltages of 1000 VACrms, ensuring safety and reliability. The series includes models with wide input voltage ranges from 9 VDC to 75 VDC and offers efficiencies up to 89%. It operates effectively within -40°C to +85°C without derating, providing precise voltage regulation, low no-load power consumption, and comprehensive protection features. This converter series integrates safety certifications including IEC, UL, and EN standards for secure deployment.
TRACO POWER TRI61211 DC/DC Converter Specifications:
- Input Voltage Range: 9-75 VDC with 2:1 ratio
- Output Power: 6 Watts
- Efficiency: Up to 89%
- Isolation Voltage: 9000 VDC (1s), 7071 VDC (60s), Rated for 1000 VAC working voltage
- Operating Temperature Range: -40°C to +85°C without derating
- Protection Features: Overload, Overvoltage, Short Circuit, Auto Recovery
- Ripple and Noise: 20 MHz bandwidth, 70 mVp-p max.
- Dimensions: Compact DIP-24 package, specific size in mm provided
- Certification: IEC 62368-1, UL 62368-1, EN 62368-1, RoHS, Reach
- No-Load Power Consumption: 120-240 mW
- Common Mode Transient Immunity: 15 kV/μs
- Surge Voltage: Up to 100 VDC at input depending on model
- Isolation Resistance: ≥10,000 MΩ at 500 VDC
- Housing Material: UL 94V-0 rated plastic
- Weight: Approximately 16.59 grams
- Cooling: Natural convection, altitude up to 5000 meters
- Soldering Profile: Wave soldering at 260°C for 10 seconds
Buy the Traco Power Series TRI Series DC/DC Converter: TRI61211
Enhance your electrical systems with the Traco Power TRI61211 high-isolation DC/DC converter. Designed for demanding industrial environments, it offers wide input voltage range, efficiency up to 89%, and reinforced safety features including high test voltages. Its compact DIP-24 package makes installation easy and space-efficient. Suitable for transportation, instrumentation, and automation systems, this converter provides precise output regulation, low no-load power consumption, and comprehensive safety certifications. Invest now to ensure reliable power conversion with durability and safety built-in.
Buy Traco Power TRI61211 now and experience unmatched reliability and high insulation performance in demanding industrial and transportation applications.
Frequently Asked Questions
Where can I buy TRACO POWER TRI61211?
You can click on the BUY or RFQ button to purchase TRI61211 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TRI61211?
You can download the TRI61211 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TRI61211?
TRACO POWER
