TRACO POWER TRI31223 High-Isolation DC/DC Converter
The TRI 3 Series is a high-isolation, regulated 3.5-watt DC/DC converter designed for industrial, transportation, and instrumentation applications. It offers reinforced isolation with withstand voltages up to 9000 VDC for 1s and 7071 VDC for 60s, along with high efficiency up to 87%. The series features a wide input voltage range of 4.5-75 VDC, low no-load power consumption, and integrated EMC filters. It operates reliably within -40°C to +90°C, providing precise, isolated outputs, compliance with IEC/EN/UL safety standards, and robust protection against overload, overvoltage, and short circuits.
TRACO POWER TRI31223 High-Isolation DC/DC Converter Specifications:
- Input Voltage Range: 4.5-75 VDC with 2:1 ratio
- Efficiency: Up to 87%
- Isolation Voltage: Rated for 1000 VAC working, withstand voltages up to 9000 VDC for 1s
- Operating Temperature: -40°C to +90°C
- No-load Power Consumption: 96-192 mW
- Protection: Overload, overvoltage, short circuit
- Safety Certifications: IEC 62368-1, UL 62368-1
- Isolation Resistance: 10,000 MΩ at 500 VDC
- Isolation Capacitance: 40 pF max at 100 kHz
- Common Mode Transient Immunity: 15 kV/µs
- Mechanical: DIP-24 package, dimensions approx 20.32 mm x 15.80 mm
- Material: UL 94V-0 rated plastic housing
- Soldering: Wave soldering at 260°C for 10s
- Start-up Time: 30 ms max
- Output Regulation: ±1%
- Ripple and Noise: 70 mVp-p at 20 MHz bandwidth
- Temperature Derating: 8.3% per K above 90°C
Buy the Buy TracoPower TRI 3 Series Part Number TRI31223 Online
Order the TracoPower TRI 3 Series TRI31223 online today to benefit from high efficiency, reinforced safety isolation, and a wide input voltage range. This 3.5-watt regulated converter offers optimal performance for industrial, transportation, and instrumentation systems, ensuring reliable operation across -40°C to +90°C temperatures. With integrated EMC filters, robust overload and overvoltage protection, and compliance with IEC/EN/UL safety standards, it’s the ideal choice for demanding technical environments. Purchase online now for quick delivery and seamless integration into your power systems, guaranteeing stability and safety in every application.
Buy TracoPower TRI 3 Series TRI31223 now and experience reliable high-isolation power conversion for demanding industrial and instrumentation applications.
Frequently Asked Questions
Where can I buy TRACO POWER TRI31223?
You can click on the BUY or RFQ button to purchase TRI31223 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TRI31223?
You can download the TRI31223 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TRI31223?
TRACO POWER
