TRACO POWER TEN61211N DC-DC Converter
The TEN 6-1211N from TracoPower is a high-performance, 6W DC-DC converter housed in a 24-pin DIP package. Designed for an optimal balance of cost and performance, it features overload protection, internal filtering compliant with EN55022 Class A, no minimum load requirement, and high efficiency. Its wide 2:1 input voltage range (9VDC to 18VDC) and tight output voltage regulation make it suitable for various applications. The converter includes continuous, automatic recovery short circuit protection and is constructed with UL 94V-0 rated non-conducting plastic and epoxy potting for safety. Typical uses include distributed power systems, workstations, computers, and communication equipment. The device provides an output of 5VDC at up to 1200mA, with an efficiency of 78%, input-to-output isolation of 1500VDC, and complies with UL/cUL 60950-1 and IEC/EN 60950-1 standards. Operating temperature range is from -40°C to +85°C, with dimensions of 20.3mm x 10.2mm x 31.8mm. It features a startup voltage of 9VDC or lower, maximum surge voltage of 25V for 1 second, and high input/output isolation resistance and capacitance suitable for industrial and power management applications.
TRACO POWER TEN61211N DC-DC Converter Specifications:
- Input Voltage Range: 9VDC to 18VDC with 2:1 ratio
- Output Voltage: 5VDC, Max Current: 1200mA
- Efficiency: 78%
- Input Current at Full Load: 610mA
- Input Current at No Load: 20mA
- Isolation Voltage: 1500VDC
- Operating Temperature: -40°C to +85°C
- Package: DIP-24 plastic
- Surge Voltage: 25V max for 1 sec
- Ripple and Noise: 80mVp-p
- Switching Frequency: 330kHz
- Soldering Max Temperature: 260°C for 10 sec
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- UL and IEC Certification: UL 60950-1, IEC/EN 60950-1
- Case Material: UL 94V-0 plastic, epoxy potting
- Weight: 13g
Buy the TracoPower Series TEN 6N DC/DC Converter: TEN61211N
Purchase the TracoPower TEN61211N DC-DC converter online today to benefit from its high efficiency, reliable overload protection, and wide input voltage range. This compact, UL 60950-1 certified power module features internal filtering, no minimum load requirement, and automatic short circuit recovery, making it ideal for distributed power systems, communication equipment, and industrial applications. With a 5V output at up to 1200mA and operating temperatures from -40°C to +85°C, it ensures dependable power conversion in demanding environments. Secure yours now for superior performance and durability.
Get TracoPower TEN61211N today—built for precision and long-lasting durability in industrial power applications.
