TRACO POWER THM304813WI Medical Power Converter
The THM 30WI series offers medical-grade 30 Watt DC/DC converters designed in a compact 2.0 x 1.0-inch plastic package. Featuring a wide 4:1 input voltage range, these converters provide reinforced isolation of 5000 VACrms, low leakage current under 2.5 pA, and operate reliably from -40°C to +80°C. Certified per IEC/EN/ES 60601-1 3rd edition for 2 X MOPP, they are suitable for medical, transportation, and industrial applications, ensuring high efficiency up to 90%, and conforming to rigorous safety and EMI standards.
TRACO POWER THM304813WI Medical Power Converter Specifications:
- Input voltage range: 9 VDC to 36 VDC with models available for 5 V, 12 V, 15 V, 24 V outputs
- Output power: 30 Watts maximum
- Efficiency: up to 90%
- Isolation voltage: 5000 VACrms with reinforced insulation
- Operating temperature: -40°C to +80°C with derating above 45°C for some models
- Input current: 9 mA to 10 mA no load, surge voltage max: 100 V
- Output voltage accuracy: ±1%, adjustable within 10-20% for some models
- Ripple & noise: 50–75 mVp-p (20 MHz bandwidth)
- Protection: Continuous short-circuit, overcurrent, and overvoltage protection
- Compliance: IEC/EN/ES 60601-1, IEC 60601-1-2, EN55032, ISO 13485
Buy the Traco Power Series THM 30WI Medical DC/DC Converter: THM304813WI
Upgrade your medical or industrial systems with the Traco Power THM304813WI series, a reliable 30 Watt DC/DC converter with reinforced 5000VACrms isolation, ultra-wide input range, and certified safety standards. Designed for demanding environments, it offers high efficiency, low leakage current, and operation from -40°C to +80°C. Easy to integrate in compact spaces, this converter ensures stable performance and compliance with IEC 60601-1, making it ideal for critical applications requiring robust power solutions. Order online today for quality and dependability.
Get Traco Power THM304813WI today—built for precision and long-lasting durability in medical and industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER THM304813WI?
You can click on the BUY or RFQ button to purchase THM304813WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM304813WI?
You can download the THM304813WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM304813WI?
TRACO POWER
