TRACO POWER TME2412S DC/DC Converter
The TME series consists of compact, high-efficiency, 1-watt isolated DC/DC converters in a SIP package requiring only 0.7 cm² of board space. Designed for industrial applications, they provide a cost-effective solution for generating isolated voltages with up to 80% efficiency and operate within a temperature range of -40°C to +85°C. Fully tested with industry-standard pinout and a 3-year warranty, these converters feature UL94V0 casing, low ripple noise, and include models with various input/output voltages tailored for diverse electronic and automation systems.
TRACO POWER TME2412S DC/DC Converter Specifications:
- Input Voltage: 3.3 VDC, 5 VDC, 12 VDC, 24 VDC
- Output Voltage: 3.3 VDC, 5 VDC, 9 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Current Max: 84 mA to 260 mA depending on model
- Efficiency: Up to 80%
- Isolation Voltage: 1000 VDC
- Temperature Range: -40°C to +85°C
- Ripple & Noise: 150 mVp-p max at 20 MHz bandwidth
- Size: Very compact SIP package, requiring only 0.7 cm² PCB area
- Operating Ambient Temperature: -40°C to +85°C
- Storage Temperature: -55°C to +125°C
- Ingress Protection: No specific IP rating, casing UL94V0 plastic
- Soldering Temperature: Max 265°C for 10s
- Reliability: MTTF over 2,000,000 hours
- Isolation Resistance: >1 GΩ
- Switching Frequency: 50 to 110 kHz
- Certification: RoHS compliant, lead-free design
Buy the TracoPower TME2412S – Reliable Isolated DC/DC Converter for Industrial Applications
Secure your supply chain with the TracoPower TME2412S DC/DC converter, a compact, high-efficiency power solution designed for industrial electronics and automation systems. This 1-watt isolated converter offers up to 80% efficiency, operating reliably within a temperature range of -40°C to +85°C. Its UL94V0 casing ensures safe operation, while industry-standard pinout simplifies integration. Ideal for generating isolated voltages in space-constrained environments, this product guarantees durability, low ripple noise, and a 3-year warranty, making it the perfect choice for engineers seeking dependable power modules online.
Buy TracoPower TME2412S now and experience unmatched reliability and high efficiency in compact form for your industrial and automation needs.
Frequently Asked Questions
Where can I buy TRACO POWER TME2412S?
You can click on the BUY or RFQ button to purchase TME2412S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME2412S?
You can download the TME2412S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME2412S?
TRACO POWER
