TRACO POWER TXM035148 48V Power Supply
The TXM035148 is a highly efficient, compact enclosed power supply rated at 48VDC with an adjustable output range of 45.6-52.8VDC. Designed for industrial and control applications, it features a robust metal casing, no internal fan, and universal AC input (90-264 VAC). It provides overload, overvoltage, and short-circuit protections, with a power output of 35 Watts. Suitable for use up to 70°C ambient temperature, it ensures reliable performance, low ripple, and noise levels. Compliant with international safety and EMI standards, ideal for demanding industrial environments.
TRACO POWER TXM035148 48V Power Supply Specifications:
- Output Voltage: 45.6-52.8VDC (adjustable)
- Output Power: 35W
- Input Voltage Range: 90-264 VAC (universal input)
- Input Frequency: 47-63 Hz
- Efficiency: 87%
- Ripple and noise: < 1.0% of Vout nom.
- Protection: Overload, overvoltage, short circuit
- Operating Temperature: -20°C to +70°C, derating above 40°C
- Isolation Voltage: Input/Output 3000 VAC
- Dimensions: Approximate L x W x H 101.6 x 55 x 30 mm
- Weight: 625 g
- Certifications: UL/cUL, IEC 60950-1, CE
Buy the Buy ENclosed Power Supplies Power TXM Series 48VDC Part Number TXM035148 Online
Purchase the TXM035148 48VDC power supply online today for reliable, high-performance industrial power solutions. With adjustable output, compact metal casing, and high efficiency up to 87%, it ensures optimal power delivery for control cabinets and automation systems. Its universal AC input simplifies installation across different regions, while protections against overcurrent, overvoltage, and short circuits guarantee safety and longevity. Ideal for demanding environments, this rugged power supply supports operation up to 70°C, meeting strict safety and EMI standards globally. Order now for fast, secure delivery.
Buy ENclosed Power Supplies Power TXM Series 48VDC TXM035148 now and experience unmatched reliability, high efficiency, and robust industrial performance.
Frequently Asked Questions
Where can I buy TRACO POWER TXM035148?
You can click on the BUY or RFQ button to purchase TXM035148 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TXM035148?
You can download the TXM035148 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TXM035148?
TRACO POWER
