TRACO POWER TXM050148 Industrial Power Supply
The TXM050148 power supply is a compact, high-efficiency enclosed power unit with a power output of 48 VDC and a maximum of 8 A current. Designed for industrial and automation applications, it features universal AC input (90-264 VAC), low no-load power consumption (<0.5 W), and adjustable output voltage. The device is capable of operating at temperatures up to 70°C, with a robust metal case and screw terminal connection for easy installation. Certifications include UL and IEC standards, ensuring safety and EMC compliance, ideal for cost-sensitive, reliable power delivery in various electronic systems.
TRACO POWER TXM050148 Industrial Power Supply Specifications:
- Output Voltage: 48 VDC (adjustable 45.6-52.8 VDC)
- Output Current: 8 A
- Power Output: 48 VDC / 8 A / 384 W
- Input Voltage Range: 90 - 264 VAC
- Input Frequency: 47 - 63 Hz
- Efficiency: 87% at nominal load
- Ripple and Noise: < 1.0 % of Vout
- Operating Temperature: -25°C to +70°C (derating above 50°C)
- Protection: Overload, overvoltage, short circuit
- Isolation Voltage: 3000 VAC (Input/Output)
- Humiditiy: 90% RH non-condensing
- Certification: UL, IEC 60950-1, EMC Standards
- Mounting: Screw terminals, metal enclosure
- Dimensions: Approximately 99 mm x 63 mm x 33 mm
Buy the Traco Power Series TXM48V: 48VDC Power Supply
Order the Traco Power TXM050148 online today and enjoy reliable and efficient power delivery with adjustable 48VDC output, 8A current capacity, universal input, compact metal case, and high efficiency. Designed for industrial automation, control systems, and electronic equipment, this high-quality power supply ensures safety compliance, low noise, and durability. Perfect for cost-sensitive projects requiring stable power and easy installation, the TXM series offers excellent value and proven dependability in demanding environments.
Get Traco Power TXM050148 today—built for precision and long-lasting durability in industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER TXM050148?
You can click on the BUY or RFQ button to purchase TXM050148 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TXM050148?
You can download the TXM050148 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TXM050148?
TRACO POWER
