TT Electronics - Optek Technology OVLAW4CB7 High-Intensity White LED
The OVLAW4CB7 is a high-intensity 3mm white LED lamp with a 40° viewing angle, designed for uniform wide-angle lighting. It features a clear lens, InGaN technology, and is suitable for indicators in medical, industrial, consumer, and automotive applications, as well as signage and architectural lighting. Its robust design ensures performance under diverse conditions, including high temperature and humidity, while providing high luminous intensity and reliability for various electronic displays and backlighting systems.
TT Electronics - Optek Technology OVLAW4CB7 High-Intensity White LED Specifications:
- Luminescent Color: White
- Lens Color: Clear
- Diameter: 3 mm
- Viewing Angle: 40°
- Maximum Storage Temperature: +100°C
- Operating Temperature Range: -40°C to +100°C
- Forward Voltage: 3.2V to 4.0V at 20mA
- Luminous Intensity: 4,360 to 6,200 mcd at 20mA
- Peak Forward Current: 100 mA (pulsed)
- Average Forward Current: 25 mA
- Reverse Voltage: 5V
- Power Dissipation: 100 mW
- Junction Temperature: 125°C
- ESD Classification: Class 1C
- Lead Soldering Temperature: 260°C for 5 seconds
- Packaging: 500 pcs per bulk bag
Buy the OPTEK OVLAW4CB7 – Reliable White LED for Industrial Applications
Order the OPTEK OVLAW4CB7 online today to benefit from high luminous intensity, wide-angle light distribution, and robust reliability. This 3mm white LED is perfect for indicators, signage, backlighting, and architectural projects, offering excellent performance even under temperature extremes and humidity. With a clear lens and InGaN technology, it delivers bright, consistent illumination for medical, automotive, consumer, and industrial uses. Purchase now to enhance your electronic and lighting applications with a proven, high-quality LED solution that ensures durability and efficiency.
Get OPTEK OVLAW4CB7 today—designed for bright, wide-angle illumination and long-lasting performance in industrial and signage lighting.
Frequently Asked Questions
Where can I buy TT Electronics - Optek Technology OVLAW4CB7?
You can click on the BUY or RFQ button to purchase OVLAW4CB7 from an authorized TT Electronics - Optek Technology distributor.
How do I troubleshoot issues or seek technical support for part OVLAW4CB7?
You can download the OVLAW4CB7 datasheet or visit the TT Electronics - Optek Technology website for support.
Who is the manufacturer of OVLAW4CB7?
TT Electronics - Optek Technology
