WAGO 26261355 PCB Terminal Strip
This is a 5-pole PCB terminal strip featuring Push-in CAGE CLAMP® connection technology. It allows push-in termination for solid and ferruled conductors, making it ideal for panel feedthrough applications with conductor entry parallel to the terminal. Testing can be performed both parallel and perpendicular to the conductor entry. The terminal strip has grey polyamide (PA66) insulation material with a UL94 V0 flammability rating. It complies with standards including IEC 60947-7-4, CSA C22.2, and KEMA/KEUR EN 60947-7-4. Designed for feed-through mounting.
WAGO 26261355 PCB Terminal Strip Specifications:
- Pole Count: 5
- Pin spacing: 12.5 mm / 0.492 inch
- Width: 59.3 mm / 2.335 inch
- Height: 23.6 mm / 0.929 inch
- Depth: 24.2 mm / 0.953 inch
- Solder pin length: 4 mm
- Solder pin dimensions: 1.5 x 1 mm
- Color: Gray
- Material: Polyamide 66 (PA66)
- Flammability rating: UL94 V0
- Contact material: Electrolytic copper, tin-plated
- Spring material: Chrome nickel spring steel
- Rated voltage: 1000V (IEC), 600V (UL)
- Rated current: 48A (IEC), 38A (UL)
- Ambient temperature range: -60°C to +105°C
- Connection: Push-in CAGE CLAMP®
- Conductor range: Solid and ferruled conductors 0.2–10 mm² / 24–8 AWG
- Maximum conductor with insulated ferrule: 6 mm²
- Mounting type: Feed-through mounting
- Approvals: UL, CSA, DEKRA, KEMA/KEUR
- Compliance: IEC 60947-7-4, UL 94 V0
Buy the WAGO 26261355 – Reliable PCB Terminal Strip for Industrial Applications
Purchase the WAGO PCB terminal strip today for robust electrical connections in industrial automation and control systems. Designed with push-in CAGE CLAMP® technology for secure, tool-free termination of solid and ferruled conductors, this 5-pole strip supports standard voltages up to 1000V and currents up to 48A. Its grey polyamide insulation features UL94 V0 flammability grade, ensuring safety and reliability. Perfect for panel feedthroughs with easy testing options, it meets IEC, UL, and CSA standards, making it the ideal choice for professionals seeking quality, safety, and ease of installation.
Get WAGO 26261355 today—built for precision and long-lasting durability in electrical and panel wiring solutions.
