WAGO 7131405 10-pole Male Header
The WAGO 713-1405 is a robust 10-pole male header specifically engineered for THT applications. Its 3.5mm pin spacing and 0.8 x 0.8mm solder pins facilitate secure and reliable connections. The header's design incorporates 100% protection against mismating, minimizing connection errors and enhancing system reliability. Constructed from polyphthalamide (PPA GF), it exhibits excellent insulation properties and a high flammability rating (UL94 V0). This header is ideal for industrial automation, control panels, and other applications requiring durable and dependable connectivity.
WAGO 7131405 10-pole Male Header Specifications:
- Pin Spacing: 3.5 mm
- Number of Poles: 10
- Solder Pin Length: 3.8 mm
- Solder Pin Dimensions: 0.8 x 0.8 mm
- Width: 19 mm
- Height: 17.3 mm
- Height from Surface: 13.5 mm
- Depth: 13.3 mm
- Drilled Hole Diameter: 1.2 mm
- Nominal Voltage (III/3): 80 V
- Rated Surge Voltage (III/3): 2.5 kV
- Nominal Voltage (II/2): 250 V
- Rated Surge Voltage (II/2): 2.5 kV
- Rated Current: 10 A
- Material: Polyphthalamide (PPA GF)
- Flammability Class: UL94 V0
- Contact Material: Electrolytic Copper (E Cu)
- Contact Plating: Tin-plated
- Weight: 2.8 g
- Operating Temperature Range: -60 … +100 °C
- Mating Direction: 90 °
- Locking: Without
