WEIDMULLER 1123290000 Relay Base
The TRS 120VUC 1CO EMPTY is a reliable electromechanical relay base designed for industrial automation and control applications. It features a single change-over contact rated for 10 A at 250 VAC, with screw connection terminals and a control voltage of 120 V UC ±10%. The device is UL listed with a V-0 flammability rating, and suitable for environments up to 60°C operating temperature. Its compact dimensions include a width of 6.4 mm and height of 89.6 mm, making it ideal for space-constrained control panels.
WEIDMULLER 1123290000 Relay Base Specifications:
- Dimensions: Width 6.4 mm, Height 89.6 mm, Depth 87.8 mm
- Weight: 299 g
- Rated control voltage: 120 V UC ±10%
- Control side: Green LED indicator, Coil voltage 60 V DC (for relay replacement)
- Load side: 10 A at 250 VAC, 1CO contact type
- Connection: Screw terminal, stripping length 8mm, Tightening torque 0.4 Nm
- Wire range: AWG 26 min, AWG 14 max, flexible and solid conductors compatible
- Environmental: Max operating temperature -40°C to 85°C, Pollution severity level 2
- Flammability rating: UL 94 V-0, Dielectric strength 4kV, Surge voltage category: TL
- Standards: DIN EN 50178, cURus approval number E223759
- Material: Polycarbonate rail mounting in black, insulated, with a protective degree of 1P20
Buy the Weidmueller TRS 120VUC 1CO EMPTY – Reliable Relay Base for Industrial Applications
Upgrade your automation setup with the Weidmueller relay base, designed for robust industrial control. Featuring a 120 V control voltage, UL certification, and 10 A switching capacity, it provides dependable operation in demanding environments. The compact size of 6.4 mm width and high-quality materials ensure easy integration into control panels. Its screw connection terminals facilitate secure wiring, while the low profile saves space. Ideal for PLC, process automation, and machine control circuits, this reliable relay base ensures consistent performance and safety compliance.
Buy Weidmueller TRS 120VUC 1CO EMPTY now and experience unmatched reliability and performance in your control systems.
Frequently Asked Questions
Where can I buy WEIDMULLER 1123290000?
You can click on the BUY or RFQ button to purchase 1123290000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1123290000?
You can download the 1123290000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1123290000?
WEIDMULLER
