WEIDMULLER 2439990000 PCB Header Connector
This is a male header connector designed for wave soldering with a 2.50 mm pitch and 10 poles. It features a straight plugging direction (180°) onto the PCB, with a robust housing variant: closed (G), packaged in a cardboard box for easy handling. Made from high-quality materials, it meets industry standards for electrical and mechanical performance, including rated voltage and current, and withstands temperature ranges up to 105°C. Perfect for automation, electronic connections, and industrial PCB assemblies requiring reliable THT solder connections.
WEIDMULLER 2439990000 PCB Header Connector Specifications:
- Pitch: 2.50 mm (0.984 inch)
- Number of poles: 10
- Solder pin length: 3.2 mm (+0.17/-0.1 mm)
- Solder eyelet hole diameter: 1.3 mm
- Pin dimensions: 0.8 x 0.8 mm
- Material: PA 66 black, copper alloy contact surface tinned
- Operating temperature: -40°C to 105°C
- Rated voltage: 320V (IEC), 150V (UL, CSA)
- Rated current: 6A (IEC), 5A (UL, CSA)
- Width: 26.9 mm, Height: 13.3 mm, Depth: 8.1 mm
- Touch-safe protection: IP0O, 25 plug cycles
- Conforms to IPC-A-610 Class 2 standards
- UL 94 V-0 flammability rating
- Color: Black (RAL 9011), CTI 2600
- Connection type: THT soldering
- Housing: Closed (G), Packaged in box (BX)
Buy the Weidmueller 2439990000 – Reliable PCB Header for Industrial Applications
Order the Weidmueller PCB Header Connector now to ensure reliable, high-quality connections for your electronic or industrial PCB assembly needs. Designed with 2.50 mm pitch and 10 poles, it guarantees secure mounting and long-term performance. Packaged in convenient boxes for easy handling, this connector conforms to international standards for safety and durability. Ideal for automation, control systems, and electronics, this PCB header provides excellent electrical performance, temperature resilience, and IP0O protection, making it an essential component for reliable industrial applications.
Get Weidmueller 2439990000 today—built for precision and long-lasting durability in industrial PCB connections.
