XP POWER ISC0348D15 DC-DC Converter
The ISB03 series is a 3W regulated DC-DC converter suitable for power management and industrial applications. It offers single and dual output configurations with a wide 4:1 input voltage range from 18V to 75V. Featuring a compact SMD package of 24mm x 18.1mm x 8.25mm and input-to-output isolation of 1500VDC, it operates over -40°C to 100°C. Additional features include remote on/off, high accuracy of ±2%, line and load regulation of approximately ±0.5%, and a switching frequency of 350kHz. It complies with IEC60950-1 and UL/cUL standards, with auto recovery short circuit protection, making it ideal for robust industrial power solutions.
XP POWER ISC0348D15 DC-DC Converter Specifications:
- Input Voltage Range: 18-75 VAC
- Output Power: 3 W
- Output Voltage Options: 5V, 9.96V, 12V, 15V, 24V, 33V, 50V
- Output Current (max): Up to 600 mA depending on model
- Input-to-Output Isolation: 1500 VDC
- Dimensions: 24 mm x 18.1 mm x 8.25 mm
- Operating Temperature: -40°C to +100°C
- Switching Frequency: 350 kHz
- Efficiency: up to 80%
- Protection: Continuous short circuit with auto recovery
- Regulations: IEC60950-1, UL/cUL60950-1
- Weight: 4.2 grams
- Remote On/Off: Yes
- Water washable Version: Optional
- Flammability: UL 94V-0 rated
- Humidity: 95% non-condensing
- Mounting: Surface-mount device (SMD) with tape & reel options
Buy the XP Power Series ISB03 DC-DC Converter: ISC0348D15
Purchase the XP Power Series ISB03 ISC0348D15 DC-DC converter online today for reliable industrial power management. With a compact design, 1500VDC isolation, and efficient operation up to 80%, this converter is ideal for demanding applications. It features a wide input voltage range, low noise, and high accuracy to ensure optimal performance. Easy to install with SMD packaging, it includes remote on/off control and auto recovery short circuit protection. Order now for fast delivery and enhanced power reliability in your projects.
Get XP Power ISB03 series ISC0348D15 today—built for precision, reliability, and durable industrial power solutions.
Frequently Asked Questions
Where can I buy XP POWER ISC0348D15?
You can click on the BUY or RFQ button to purchase ISC0348D15 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ISC0348D15?
You can download the ISC0348D15 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ISC0348D15?
XP POWER
