XP POWER IMM0212D12 Medical DC-DC Converter
The IMM02 series is a 2W DC-DC converter housed in an 8-pin SIP package, compliant with worldwide medical standards including UL ANSI/AMMI ES60601-1, CSA C22.2 No. 60601-1, TUV EN60601-1, and CB IEC60601-1. It features single and dual output options, operates within a temperature range of -20°C to 100°C, and can deliver full load at an ambient temperature of 60°C. The device provides 1500VAC isolation with 1 x MOPP and meets Level B conducted and radiated noise standards (EN55011). Suitable for medical, industrial, and power management applications.
XP POWER IMM0212D12 Medical DC-DC Converter Specifications:
- Power: 2 Watts
- Input Voltage Range: 3V3, 5V, 12V, 18V, 45-90V, 9V-18V
- Output Voltage: 3.3V, 5V, 12V, 15V, 23.3V, 25V
- Output Current: 75 mA to 303 mA depending on model
- Isolation Voltage: 1500 VAC with 1 x MOPP at 250VAC
- Operating Temperature Range: -20°C to +100°C
- Full Load at 60°C Ambient
- Model Dimensions: 0.86 x 0.36 x 0.44 inches (21.85 x 9.2 x 11.1 mm)
- Case Material: SIP8 package
- Certifications: UL, ANSI/AMMI ES60601-1, CSA, TUV EN60601-1, CB IEC60601-1
- Ripple & Noise: 7% pk-pk @ 20 MHz bandwidth
- Efficiency: Up to 79%
- Isolation Resistance: ≥75 MΩ at 250V
- Switching Frequency: 175 kHz to 7 kHz (burst mode at light load)
- MTBF: 1 million hours
- Operating Humidity: Non-condensing
- Cooling: Natural convection
Buy the XP Power IMM0212D12 – Reliable Medical DC-DC Converter for Industrial Applications
Purchase the XP Power IMM0212D12 online today—designed for reliable performance in medical, industrial, and power management applications. This 2W converter offers 1500VAC isolation, operates across a wide temperature range from -20°C to 100°C, and features dual outputs with certified compliance to global medical standards like UL and EN60601-1. Its compact SIP8 package makes it ideal for space-constrained designs needing high efficiency, low ripple, and robust electrical isolation. Order now for superior quality and dependable operation.
Get XP Power IMM0212D12 today—built for precision and long-lasting durability in medical and industrial environments.
Frequently Asked Questions
Where can I buy XP POWER IMM0212D12?
You can click on the BUY or RFQ button to purchase IMM0212D12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part IMM0212D12?
You can download the IMM0212D12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of IMM0212D12?
XP POWER
