XP POWER ITP0324D15 DC-DC Converter Module
The ITP series offers a compact 3W DC-DC converter module that is cost-effective and suitable for various industrial applications. It features wide input voltage ranges (4.5 to 18V, 9 to 36V, or 18 to 75V DC) and provides regulated single or dual outputs from 3.3V to 15V DC with 1% voltage regulation. The module is housed in an ultra-compact SIP6 package with 1.6kV DC input/output isolation, high efficiency, and compliance with EN55032 standards. It includes short-circuit protection, remote On/Off (for single output models), and operates across a temperature range of -40°C to +75°C, maintaining full power up to +70°C.
XP POWER ITP0324D15 DC-DC Converter Module Specifications:
- Input Voltage Range: 4.5 to 18V, 9 to 36V, 18 to 75V DC
- Output Power: 3 Watts
- Output Voltage: 3.3V to 15V DC regulated
- Output Current: Up to 700mA depending on model
- Voltage Regulation: 1%
- Isolation: 1.6kV DC input/output
- Efficiency: Up to 84%
- Operating Temperature: -40°C to +75°C
- Full Power Temperature: Up to +70°C
- Package: SIP6 ultra-compact
- Short-circuit and overload protection
- Remote On/Off (single-output models only)
- Standards: EN55032
- MTBF: Over 0.95 million hours
- Warranty: 3 years
Buy the Buy XP Power ITP Series 3W Part Number ITP0324D15 Online
Purchase the XP Power ITP0324D15 3W DC-DC converter online today to benefit from a reliable, compact power solution designed for industrial environments. This high-efficiency module offers wide input voltage ranges from 4.5V to 75V DC, regulated outputs from 3.3V to 15V, and features input/output isolation of 1.6kV DC. Its robust SIP6 package ensures durability across temperatures from -40°C to +75°C. With short-circuit protection, remote On/Off capability, and compliance with EN55032 standards, this converter guarantees optimal performance for demanding applications with a 3-year warranty.
Order your XP Power ITP0324D15 3W industrial DC-DC converter today and ensure reliable power regulation for your critical applications.
Frequently Asked Questions
Where can I buy XP POWER ITP0324D15?
You can click on the BUY or RFQ button to purchase ITP0324D15 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0324D15?
You can download the ITP0324D15 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0324D15?
XP POWER
