XP POWER ITP0324S3V3 DC-DC Converter
The ITP series offers a compact, 3-watt DC-DC converter designed for industrial applications, featuring wide input voltage ranges and high efficiency up to 84%. It has regulated single and dual outputs, with an isolation of 1.6kVDC. Encased in a SIP6 package, it operates reliably from -40°C to +75°C, with full power up to +70°C. Suitable for rugged environments, the module includes short-circuit protection, remote On/Off for single outputs, and complies with EN55032 standards, making it ideal for industrial, automation, and control systems.
XP POWER ITP0324S3V3 DC-DC Converter Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5-18 V, 9-36 V, 18-75 V with models for each range
- Output Voltage Options: 3.3V, 5.0V, 12.0V, 15.0V, +5.0V, +12.0V, +15.0V
- Maximum Output Current: 700mA at 3.3V, 600mA at 5V, 250mA at 12V, 200mA at 15V
- Input/Output Isolation: 1.6kVDC
- Efficiency: Up to 84%
- Operating Temperature: -40°C to +75°C, full power to +70°C
- Dimensions: 0.67 x 0.40 x 0.46 inches (17.0 x 10.1 x 11.7 mm)
- Short-circuit protection: Yes
- Remote On/Off: Yes (single output models only)
- Complies with EN55032 EMI standards
- MTBF: Over 0.95 million hours
- Warranty: 3 years
Buy the XP Power ITP0324S3V3 – Reliable DC-DC Converter for Industrial Applications
Purchase the XP Power ITP0324S3V3 DC-DC converter online today to ensure reliable power conversion for your industrial automation projects. This 3-watt module delivers high efficiency up to 84%, wide input voltage ranges, and regulated outputs ideal for demanding environments. Its compact SIP6 package makes it easy to integrate into space-constrained systems. Built with rugged construction, short-circuit protection, and compliance with EMI standards, it guarantees dependable performance in industrial temperature conditions, backed by a 3-year warranty. Order now for immediate availability and seamless integration into your engineering solutions.
Get XP Power ITP0324S3V3 today—built for precision, high efficiency, and long-lasting durability in industrial control systems.
Frequently Asked Questions
Where can I buy XP POWER ITP0324S3V3?
You can click on the BUY or RFQ button to purchase ITP0324S3V3 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0324S3V3?
You can download the ITP0324S3V3 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0324S3V3?
XP POWER
