XP POWER ITP0348S15 DC-DC Power Module
The ITP series is a compact 3W DC-DC power module designed for cost-effective applications requiring a broad input voltage range and precise regulation to 1%. It features regulated single and dual outputs ranging from 3.3V to 15V DC, with a wide 4:1 input voltage range (4.5 to 18V, 9 to 36V, or 18 to 75V DC). Encased in an ultra-compact SIP6 package, it provides 1.6kV DC input/output isolation, high efficiency, and compliance with EN55032 standards. The module includes short-circuit protection, remote On/Off (for single output models), and operates over an extended temperature range from -40°C to +75°C, delivering full power up to +70°C, making it suitable for industrial applications.
XP POWER ITP0348S15 DC-DC Power Module Specifications:
- Power Output: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75V DC
- Output Regulation: 1%
- Output Voltages: 3.3V, 5V, 12V, 15V (regulated)
- Output Current: Up to 700mA depending on model
- Isolation Voltage: 1.6kV DC
- Efficiency: Up to 83%
- Input-Output Isolation: 1.6kV DC
- Operating Temperature Range: -40°C to +75°C
- Full Power Temperature: up to +70°C
- Package: SIP6 Ultra-compact
- Compliance: EN55032, UL62368-1, CE LVD
- Features: Short-circuit protection, Remote On/Off (single output models)
- Dimensions: Approximately 17.0 x 10.1 x 11.7 mm
- MTBF: >0.95 million hours
Buy the XP Power Series DC-DC Converter: ITP0348S15
Purchase the XP Power ITP0348S15 online today and benefit from a reliable 3W DC-DC converter with wide input voltage adaptability, regulated output, high efficiency, and robust industrial temperature operation. Perfect for cost-effective and space-saving applications, this module ensures consistent performance with short-circuit protection, remote On/Off, and substantial isolation ratings. Its compact SIP6 package makes installation simple for industrial and embedded systems, providing durability, compliance with international standards, and long MTBF for mission-critical projects. Secure yours now for dependable power solutions.
Buy XP Power ITP0348S15 now and experience unmatched reliability and industrial-grade performance in a compact package.
Frequently Asked Questions
Where can I buy XP POWER ITP0348S15?
You can click on the BUY or RFQ button to purchase ITP0348S15 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0348S15?
You can download the ITP0348S15 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0348S15?
XP POWER
