XP POWER ITV2405S DC-DC Converter
This 1W unregulated DC-DC converter features auto-recovery short-circuit protection, operating across -40°C to +105°C. It offers single and dual output options within a compact SIP7 package, supporting full load at 95°C ambient. With 3000VDC isolation and Class B radiated emissions compliance, it is ideal for industrial and signal processing applications. Its robust encapsulated design ensures durability, making it suitable for high-temperature environments. The converter provides reliable performance in demanding industrial control systems, with protection features and a small footprint for versatile integration.
XP POWER ITV2405S DC-DC Converter Specifications:
- Power: 1 Watt
- Input Voltage Range: 10.8V to 13.2V (12V nominal), 21.6V to 26.4V (24V nominal)
- Output Voltage Options: 5V, 12V, 15V, 25V, 26V, 15V, 22V, 24V
- Output Current (max): 416 mA (for 26V output), 333 mA (for 15V), 200 mA (for 5V)
- Isolation Voltage: 3000 VDC
- Operating Temperature: -40°C to +105°C
- Package Type: SIP7
- Dimensions: 0.76 x 0.24 x 0.39 inches (19.5 x 6.0 x 10.0 mm)
- Full load at 95°C ambient, supports short circuit protection and Class B radiated emissions
- MTBF: Over 3.5 million hours
- Compliance: CE, UKCA
- Efficiency: Up to 81%
- Isolation Resistance: 10 MΩ
- Switching Frequency: 40/50 kHz
- Weight: 0.0053 lbs (2.4 g)
- Environmental Protection: Natural convection cooling
Buy the Buy XP Power DC-DC Converter Part Number ITV2405S Online
Secure the XP Power ITV2405S online today to ensure your industrial and signal processing projects benefit from its compact design, reliable 1W power output, and excellent temperature tolerance. With 3000VDC isolation, short circuit protection, and high efficiency, this converter guarantees durability and optimal performance in demanding environments. Its SIP7 package fits easily into tight spaces, making it ideal for applications requiring stable voltage regulation, noise filtering, and robust operation across wide temperature ranges. Don’t miss out—purchase now and upgrade your power solutions.
Buy XP Power ITV2405S now and experience unmatched reliability and high-temperature performance with robust short-circuit protection and versatile industrial applications.
Frequently Asked Questions
Where can I buy XP POWER ITV2405S?
You can click on the BUY or RFQ button to purchase ITV2405S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITV2405S?
You can download the ITV2405S datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITV2405S?
XP POWER
