XP POWER ITV1212SA DC-DC Converter
The ITV series is a 1W unregulated DC-DC converter featuring auto-recovery short-circuit protection. It offers both single and dual output configurations and operates across a temperature range of -40°C to 105°C. The converter comes in a SIP package, providing full load performance at an ambient temperature of 95°C. It includes 3000VDC isolation and complies with Class B radiated emissions standards. Suitable for signal processing and industrial applications, it features rugged encapsulation, high reliability, and consistent power conversion for demanding environments.
XP POWER ITV1212SA DC-DC Converter Specifications:
- Power: 1 Watts
- Input Voltage Range: 10.8 to 13.2 VDC (12V nominal), 21.6 to 26.4 VDC (24V nominal), 5V, 12V, 15V, 26V output options
- Output Voltage: 5V, 12V, 15V, 26V variants
- Operating Temperature Range: -40°C to +105°C
- Package: SIP7
- Isolation Voltage: 3000 VDC
- Efficiency: up to 81%
- Dimensions: 0.76 x 0.24 x 0.39 inches (19.5 x 6.0 x 10.0 mm)
- MTBF: >3.5 million hours
- Protection: Auto-recovery short-circuit protection
- Radiated Emissions: Class B compliance
- Operating Ambient: Full load at 95°C
- Material: Encapsulated robust plastic
- Safety Standards: CE, UKCA
- Weight: approximately 2.4 grams
Buy the Buy XP Power ITV Series DC-DC Converter Part Number ITV1212SA Online
Explore the high-quality XP Power ITV series 1W unregulated DC-DC converters available online. Designed for industrial and signal processing applications, these converters deliver reliable performance with superb efficiency up to 81%, operational across -40°C to 105°C, and feature 3000VDC isolation. Encapsulated in a SIP package, they ensure durability and ease of installation. Purchase now to benefit from quick delivery, industry-leading quality, and a 3-year warranty, making them ideal for demanding electronic projects.
Buy XP Power ITV Series DC-DC Converter parts, including ITV1212SA, now and experience unmatched reliability, high temperature operation, and robust industrial performance.
Frequently Asked Questions
Where can I buy XP POWER ITV1212SA?
You can click on the BUY or RFQ button to purchase ITV1212SA from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITV1212SA?
You can download the ITV1212SA datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITV1212SA?
XP POWER
