XP POWER IU1203SA Regulated DC-DC Converter
The IU1203SA is a regulated DC-DC converter offering reliable 2-watt power in compact SIP or DIP packages, suitable for industrial automation and control systems. It features a wide 2:1 input voltage range of 9.0-18.0V or 18.0-36.0V, with optional 3000 VDC isolation, continuous short circuit protection, and high efficiency up to 22%. Designed for harsh environments, it operates from -40°C to +85°C and is UL62368-1, CE, and UKCA approved. The converter includes remote On/Off, low ripple/noise, and is ideal for industrial electronics requiring stable power supply, high isolation, and compact form factor.
XP POWER IU1203SA Regulated DC-DC Converter Specifications:
- Input Voltage Range: 9.0-18.0V or 18.0-36.0V
- Input Ripple Current: 35 mA pk-pk through 12 UH inductor, 5-20 MHz
- Input Filter: Capacitor, See table
- Output Power: 2 Watts
- Output Voltage: Adjustable; details in specifications
- Minimum Load: 25%
- Line Regulation: ±0.5%
- Load Regulation: ±1% for 25-100% load change
- Setpoint Accuracy: ±1%
- Cross Regulation: 5% on dual output models
- Ripple & Noise: 80 mV pk-pk max, 20 MHz bandwidth
- Short Circuit Protection: Continuous with auto recovery
- Max Capacitive Load: See table
- Remote On/Off: Optional on SIP package model
- Temperature Coefficient: 0.02%/°C
- Efficiency: Up to 22%
- Isolation Voltage: 1000 VDC, optional 3000 VDC
- Isolation Resistance: >1.61 MΩ to MIL-HDBK-217F at 25°C
- Isolation Capacitance: 60 pF
- Switching Frequency: 100-650 kHz
- MTBF: >1.61 million hours
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +125°C
- Case Temperature: +100°C max
- Cooling: Convection cooled
- Safety Approvals: UL62368-1, CE, UKCA
- Dimensions: SIP and DIP packages, detailed measurements provided, case tolerance ±0.02 inches
- Weight: SIP 4.0 grams, DIP 6.0 grams
Buy the Industrial Power Supplies – Reliable DC-DC Converter for Industrial Applications IU1203SA
Enhance your industrial power setup with the IU1203SA regulated DC-DC converter, offering 2W power, wide input range, and high isolation. Its compact SIP or DIP form factor fits seamlessly into various industrial automation applications. With features like remote On/Off, high efficiency up to 22%, and comprehensive safety approvals including UL and CE, this converter ensures stable, reliable power in harsh environments. Perfect for industrial electronics, control systems, and automation projects needing durable, compact, and efficient power conversion.
Buy IU1203SA now and experience unmatched reliability and performance for industrial automation and control systems.
Frequently Asked Questions
Where can I buy XP POWER IU1203SA?
You can click on the BUY or RFQ button to purchase IU1203SA from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part IU1203SA?
You can download the IU1203SA datasheet or visit the XP POWER website for support.
Who is the manufacturer of IU1203SA?
XP POWER
