XP POWER JCA1005S12 industrial power supply
The JCA1005S12 is a compact industrial power supply featuring a 1.0” x 0.8” metal package, offering reliable 2:1 input ranges for single and dual outputs. It operates from -40°C to +100°C and is UL, CB, and TUV approved, ensuring safety and quality. Key specifications include input voltages of 5V, 12V, 24V, and 48V, with efficiencies up to 85-90%. It provides 1500 VDC isolation, switching frequency of 300 kHz, and is convection cooled, making it ideal for industrial automation and control applications needing stable, high-density power modules.
XP POWER JCA1005S12 industrial power supply Specifications:
- Input Voltage Range: 5V (4.5-9.0 VDC), 12V (9-18 VDC), 24V (18-36 VDC), 48V (36-75 VDC)
- Input Current: 80 mA at 5V input, 30 mA for others
- Operating Temperature: -40°C to +100°C with power derating
- Output Voltages: 5V, 12V, 24V, 48V with accuracy ±1%
- Efficiency: Up to 85-90%
- Isolation: 1500 VDC from input to output, 500 VDC input to case, 500 VDC output to case
- Switching Frequency: 300 kHz
- Power Density: 31.25 W/in²
- MTBF: >950,000 hours at 25°C
- Cooling Method: Convection cooled
- Humidity: Up to 95% RH, non-condensing
- Certifications: UL60950-1, EN60950-1, CE LVD
- Protection: Overcurrent, short circuit, overvoltage, auto recovery
- Dimensions: Approximate 1.0” x 0.8” x suitable height, weight 0.03 lbs
Buy the Industrial Power Modules 1005S12 – Reliable Power Supply for Industrial Applications
Order the JCA1005S12 industrial power supply online now to guarantee a reliable, high-performance solution for your automation, control, and manufacturing needs. With UL, TUV, and CB approvals, it offers excellent safety standards, high efficiency of up to 90%, and comprehensive protection features including overcurrent, short circuit, and overvoltage protection. Its compact design and convection cooling make it ideal for space-constrained industrial applications, ensuring long-lasting, stable power delivery across a wide temperature range from -40°C to +100°C. Enhance your system’s performance by purchasing online today.
Get JCA1005S12 today—engineered for high efficiency and rugged reliability in industrial environments.
Frequently Asked Questions
Where can I buy XP POWER JCA1005S12?
You can click on the BUY or RFQ button to purchase JCA1005S12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JCA1005S12?
You can download the JCA1005S12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JCA1005S12?
XP POWER
