XP POWER JCA1012S05 Power Module
The JCA1012S05 is a compact, high-efficiency DC-DC power module measuring 1.0 x 0.8 inches, designed for versatile input ranges and robust performance. Operating from 5V to 48V input, it provides 5V, 12V, 24V, or 48V outputs with excellent line and load regulation, transient response, and overcurrent/overvoltage protections. Its wide temperature range from -40°C to +100°C and UL, CB, TUV certifications make it suitable for industrial, medical, and automation applications. Convection cooled with a power density of 31.25 W/in* ensures reliable operation in demanding environments.
XP POWER JCA1012S05 Power Module Specifications:
- Compact size: 1.0 x 0.8 inches
- Input Voltage Range: 5V (4.5-9.0 VDC), 12V (9-18 VDC), 24V (18-36 VDC), 48V (36-75 VDC)
- Input Current: 80 mA at 5V, 30 mA for others
- Efficiency: up to 85%
- Isolation: 1500 VDC Input to Output, 500 VDC Input/Output to Case
- Operating Temperature: -40°C to +100°C
- Start-up Delay: 30 ms
- Start-up Rise Time: 3.5 ms
- Ripple & Noise: 50 mV pk-pk at 20 MHz bandwidth
- Overcurrent/Overvoltage Protection: Yes, auto recovery with hiccup mode
- Dimensions: 1.0 x 0.8 inches, case max temp +100°C
- Certifications: UL, CB, TUV, CE LVD
- Switching Frequency: 300 kHz typical
- Power Density: 31.25 W/in*
- Storage Temperature: -55°C to +125°C
- Cooling: Convection cooled
- EMC & Safety: EN55022, IEC60950-1, UL60950-1, CSA, CE
Buy the TechPower Series Power Module: JCA1012S05
Select the TechPower Series JCA1012S05 power module today for reliable, high-efficiency power conversion in your industrial and automation systems. Its compact size, wide input/output range, and extensive safety certifications ensure optimal performance across demanding environments. With a broad operating temperature from -40°C to +100°C and robust protections against overcurrent, overvoltage, and short circuits, it guarantees safety and longevity. Easy to install and convection cooled, this module enhances your projects with stable power supply and minimal maintenance. Order online now to experience superior quality and quick delivery.
Order your TechPower Series JCA1012S05 today and give your industrial projects the dependable, efficient power supply they need.
Frequently Asked Questions
Where can I buy XP POWER JCA1012S05?
You can click on the BUY or RFQ button to purchase JCA1012S05 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JCA1012S05?
You can download the JCA1012S05 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JCA1012S05?
XP POWER
