XP POWER JCE0612S05 industrial power supply
The JCE Series power supply features a 2:1 input range, DIP-24 plastic or optional metal case, and operates from -40°C to +100°C. It provides single and dual outputs with options for 12V, 24V, and 48V. It offers up to 1500 VDC isolation and is suitable for various industrial applications requiring high reliability. Designed for convection cooling, it includes safety approvals like UL60950-1, with features like overcurrent and short circuit protection, and an efficiency of up to 80%. Its rugged construction ensures performance in harsh environments and broad temperature ranges.
XP POWER JCE0612S05 industrial power supply Specifications:
- Input Voltage Range: 9-36VDC, 18-75VDC
- Input Current: 20 mA pk-pk (at 12V model), see table for others
- Input Filter: Pi network with 20 mA pk-pk through inductor and 4.7 UF capacitor
- Input Surge: 25 VDC (12V), 50 VDC (24V), 100 VDC (48V) for 100 ms
- Under Voltage Lockout: on >8.5V (12V), >16.5V (24V), >34.5V (48V)
- Output Voltage: 12V (9-18V), 24V (18-36V), 48V (36-75V)
- Output Voltage Balance: +2% max, dual output models
- Initial Set Accuracy: ±2%
- Minimum Load: No minimum load required
- Line Regulation: 1.2% max for single, 5% max for dual output
- Load Regulation: 20.5% max
- Cross Regulation: 3% max deviations
- Start Up Delay: 20 ms typical
- Ripple & Noise: 80 mV pk-pk (100 mV for D24 models), 20 MHz bandwidth
- Transient Response: 3% max deviation within 300 ps
- Overload Protection: Trip and restart (hiccup mode)
- Short Circuit Protection: auto recovery
- Maximum Capacitive Load: 135% - 185% of full load
- Temperature Coefficient: 0.02%/°C max
- Efficiency: up to 80%
- Isolation Voltage: 1500 VDC, optionally 3000 VDC
- Operating Temperature: -40°C to +100°C
- Case Temperature: Max +100°C
- Storage Temperature: -55°C to +125°C
- Cooling: Convection-cooled
- Operating Humidity: Up to 95% RH, non-condensing
- Emissions: EN55022 Class A
- ESD Immunity: EN61000-4-2, Level 3
- Radiated Immunity: EN61000-4-3, 10 V/m
- Surge Immunity: EN61000-4-5, Level 2
- Conducted Immunity & Magnetic Field: EN61000-4-6 & EN61000-4-8
- Safety Approvals: UL60950-1, CSA C22.2 No.60950-1
Buy the Power Supply 012 – Reliable Industrial Power Solutions for Industrial Applications
Enhance your industrial systems' reliability with this high-performance power supply featuring 2:1 input range, high isolation, and operating temperatures from -40°C to +100°C. Its versatile single and dual outputs support 12V, 24V, and 48V configurations, with protection features for overcurrent and short circuits. Designed for convection cooling, it adheres to safety standards like UL60950-1, ensuring safe, efficient, and dependable operation in harsh environments. Ideal for industrial automation, manufacturing, and control systems requiring robust power solutions.
Buy JCE Series power supply now and experience unmatched reliability and high efficiency for your industrial systems.
Frequently Asked Questions
Where can I buy XP POWER JCE0612S05?
You can click on the BUY or RFQ button to purchase JCE0612S05 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JCE0612S05?
You can download the JCE0612S05 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JCE0612S05?
XP POWER
