BROADCOM HEDL5640A13 encoder line driver
Line Drivers are designed for HEDS-55xx/56xx and HEDS-9000/9100/9200/9040/9140 encoders, providing enhanced performance in noisy environments and long-distance driving. Utilizing industry-standard AM26C31Q IC with complementary outputs, these drivers feature a single 5 V supply, onboard bypass capacitor, and are suitable for non-safety-critical applications. They include a 10-conductor ribbon cable termination, operate from -40°C to 100°C, and have physical dimensions matching encoder packages. Compatible with various encoder models, they improve signal integrity for various industrial automation and motion control applications.
BROADCOM HEDL5640A13 encoder line driver Specifications:
- Operational Temperature Range: -40°C to 100°C
- Supply Voltage: 5 V DC
- Outputs: Complementary signals A, A, B, B, I/I for three-channel versions
- Connection: 10-conductor IDC ribbon cable
- Line Driver IC: AM26C31Q with decoupling capacitor onboard
- Physical Dimensions: Refer to encoder datasheets, typical sizes in millimeters, with maximum height of 0.450 inches
- Material: Standard industrial electronic components, robust and reliable
- ESD Handling: Use precautions against static discharge
- Compatibility: Suitable for noisy environments and long-distance signal transmission
- Housing: Available on both encoder modules and kits for flexible use
Buy the Buy Avago Technologies Encoder Line Driver Part Number HEDL-5640A13 Online
Purchase the Avago Technologies encoder line driver HEDL-5640A13 online today to enhance your encoder's signal integrity and operational distance. Designed for easy integration with HEDS series encoders, this line driver offers reliable complementary outputs and industry-standard IC technology. Its robust construction ensures stable operation in demanding industrial settings, reducing signal noise and improving accuracy. Ideal for automation systems requiring long cable runs or noisy environments, buying online guarantees quick delivery and genuine quality for your control system needs.
Buy Avago Technologies encoder line driver HEDL-5640A13 now and experience unmatched reliability and performance in noisy industrial environments.
Frequently Asked Questions
Where can I buy BROADCOM HEDL5640A13?
You can click on the BUY or RFQ button to purchase HEDL5640A13 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part HEDL5640A13?
You can download the HEDL5640A13 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of HEDL5640A13?
BROADCOM
