BROADCOM HFBR-1415TZ Datasheet & Stock

The HFBR-1415TZ is a 820nm miniature link Fibre Optics Transmitter with threaded ST port. The device is designed to provide high performance fibre optic communication links for information systems with link distances of up to 2.7km. The transmitter is directly compatible with popular industry-standard ST® connector. They are completely specified with multiple fibre sizes including 50/125µm, 62.5/125µm, 100/140µm and 200µm.




Signal Rates up to 160MBd

Repeatable ST Connections within 0.2dB typical

Unique optical port design for efficient coupling

Auto-insertable and wave solderable

No board mounting hardware required

AlGaAs Emitters 100% burn-in ensures high reliability

-40 to 85°C Operating temperature range





Applications


Computers & Computer Peripherals,

Fibre Optics,

Imaging, Video & Vision,

Industrial,

Communications & Networking





Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
