KEYSIGHT TECHNOLOGIES N8482A Thermocouple Power Sensor

The N8482A from Keysight Technologies is a high-accuracy thermocouple power sensor with EEPROM storage for calibration data, enabling direct measurement of RF and microwave power through the heating effect on a terminating load. It features a wide frequency range from 100 kHz to 6 GHz, with a maximum SWR from 1.06 to 1.57 across 0°C to 55°C, and a dynamic range from -35 dBm to +20 dBm. The sensor offers excellent power linearity of less than 1%, high repeatability, and accurate calibration traceable to the US National Institute of Standards and Technology. It is compatible with the 8480 series power meters using SCPI commands (option CFT) and measures average power supplied by sources or DUTs. Its compact dimensions are 38mm W x 30mm H x 130mm L.

View N8482ADatasheet [pdf]

Buy the Buy Keysight N8482A Thermocouple Power Sensor Part Number N8482A Online

Purchase the Keysight N8482A thermocouple power sensor online to benefit from high accuracy, wide frequency range from 100 kHz to 6 GHz, and excellent linearity under 1%. Its EEPROM calibration data facilitates enhanced measurement reliability, making it ideal for RF and microwave applications in metrology labs or testing environments. The sensor’s compact size ensures easy integration into your test setup, providing consistent and traceable measurements for sources or device under test. Get your high-performance power measurement ready today with quick online ordering.

Order your Keysight N8482A Thermocouple Power Sensor today and ensure precise RF and microwave power testing with reliable, high-performance measurement accuracy.
