MOLEX 2074580004 L1NK 396 Receptacle Housing
The MOLEX 207458-0004 L1NK 396 Receptacle Housing is a crucial component within the L1NK connector system, engineered for robust wire-to-board connections. This housing accommodates a maximum of 4 circuits and is molded from durable nylon resin, offering excellent insulation and mechanical strength. Its UL 94V-0 flammability rating ensures safety in various applications. Designed for ease of use, it features polarized and stackable capabilities, and mates with 207478 and 207479 headers. It is commonly used in power applications and is a reliable choice for demanding industrial environments.
MOLEX 2074580004 L1NK 396 Receptacle Housing Specifications:
- Circuits (maximum): 4
- Color - Resin: Black
- Flammability: 94V-0
- Gender: Receptacle
- Glow-Wire Capable: Yes
- Lock to Mating Part: Yes
- Material - Resin: Nylon
- Net Weight: 1.480 g
- Number of Rows: 1
- Packaging Type: Bag
- Panel Mount: No
- Pitch - Mating Interface: 3.96mm
- Pitch - Termination Interface: 3.96mm
- Polarized to Mating Part: Yes
- Stackable: No
- Temperature Range - Operating: -40° to +105°C
- UPC: 191130115587
- Application: Power, Wire-to-Board
- Mates With: L1NK 396 Headers 207478, 207479
- Use With: MarKK Crimp Terminal 455703000, L1NK TPA Retainer 207459
- EU ELV: Not Relevant
- EU RoHS: Compliant
- REACH SVHC: Not Contained Per -ED/88/2018
- Halogen-Free Status: Not Low-Halogen
