MOLEX 22022065 PCB Receptacle
The KK 254 PC Board Connector from Molex is a top-entry, 2.54mm pitch connector designed for reliable board-to-board signal connections. Featuring 6 circuits with tin plating and hooks for secure mating, it is suitable for compact electronic assemblies. Built with brass metal and nylon resin, it offers excellent electrical performance with a maximum current of 2.5A per contact and a voltage rating of 500V. Compliant with RoHS and UL standards, this connector ensures durability and safety in industrial and electronic applications worldwide. It is ideal for use in PCB interconnection systems requiring secure, high-quality connections.
MOLEX 22022065 PCB Receptacle Specifications:
- Circuits: 6
- Maximum Circuits: 6
- Color: Natural (White)
- Flammability: 94V-0
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Net Weight: 0.635g
- Number of Rows: 1
- Orientation: Vertical
- PC Tail Length: 3.35mm
- PCB Thickness - Recommended: 1.60mm
- Pitch - Mating Interface: 2.54mm
- Current - Maximum per Contact: 2.5A
- Voltage - Maximum: 500V
- Termination Interface: Style: Through Hole
- Temperature Range - Operating: Not specified
- Surface Mount Compatible (SMC): No
- RoHS Compliant
- UL Listed
Buy the Buy Molex KK 254 Part Number 0022022065 Online
Purchase the Molex KK 254 PCB Receptacle online and experience reliable board-to-board signal connections with secure hooks and tin-plated contacts. This 6-circuit, top-entry connector ensures high performance in electronic assemblies, with UL and RoHS compliance for safety and environmental standards. Its robust brass and nylon construction provide durability, while its 2.54mm pitch makes it suitable for compact, high-density applications. Buy now to ensure your electronic projects and industrial equipment benefit from quality, reliable interconnects built for long-lasting performance.
Get Molex KK 254 today—designed for secure PCB connections with high durability and reliable signal integrity.
Frequently Asked Questions
Where can I buy MOLEX 22022065?
You can click on the BUY or RFQ button to purchase 22022065 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 22022065?
You can download the 22022065 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 22022065?
MOLEX
