MOLEX 511980200 Wire-to-Wire Plug Housing
The Mini-Lock wire-to-wire plug housing features a 2.50mm pitch with a positive lock mechanism, panel mount capability, and two circuits in a natural resin. Made of durable polyester, it is designed for signal applications requiring reliable connections. This component supports operating temperatures from -40°C to +105°C and complies with RoHS, China RoHS, and REACH standards. Suitable for use with compatible connectors and suitable for panel mounting, it offers a robust, space-efficient solution for wiring applications with flammability rating UL 94V-0.
MOLEX 511980200 Wire-to-Wire Plug Housing Specifications:
- Pitch - Mating Interface: 2.50mm
- Number of Circuits: 2
- Color - Resin: Natural
- Material - Resin: Polyester
- Flammability Rating: UL 94V-0
- Operating Temperature Range: -40°C to +105°C
- Panel Mount: Yes
- Gender: Plug
- Glow-Wire Capable: No
- Keying to Mating Part: None
- Stackable: No
- Packaging Type: Bag
- Net Weight: 940 mg
- Series: 51198
- Application: Signal, Wire-to-Wire
- Status: Active
- RoHS and China RoHS Compliant
- Agency Certifications: UL, CSA
Buy the Molex Series 51198 Mini-Lock Wire-to-Wire Plug Housing: 0511980200
Discover the reliable Molex Series 51198 Mini-Lock Wire-to-Wire Plug Housing, offering a 2.50mm pitch, positive lock, panel mount, and high-temperature resistance. This signal connector is crafted from durable polyester with a UL 94V-0 flammability rating, ensuring safety and durability across industrial applications. Its compact design supports two circuits seamlessly, making it ideal for space-constrained environments. RoHS and REACH compliance guarantee eco-friendly construction. Perfect for seamless signal wiring in manufacturing, control panels, and electronic projects requiring dependable and standards-compliant connections.
Order your Molex Series 51198 Mini-Lock 0511980200 today and ensure your wiring connections are reliable and compliant with safety standards in your projects.
