MOLEX 901471105 PCB Connector
The C-Grid PC Board Connector is a vertical, single-row connector with 5 circuits, designed for board-to-board applications. Made of phosphor bronze with tin plating, it features a 2.54mm pitch, operating within -55°C to +105°C. This RoHS-compliant, UL and CSA-certified connector has a black 94V-0 resin housing, a maximum current of 3A per contact, and a maximum voltage of 350V. It is suitable for signal transmission, with a through-hole termination style, and supports reliable PCB retention and mating, making it ideal for compact electronic assemblies.
MOLEX 901471105 PCB Connector Specifications:
- Circuits (Loaded): 5
- Circuits (Maximum): 5
- Color - Resin: Black
- Flammability: 94V-0
- Guide to Mating Part: None
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 0.436 grams
- Number of Rows: 1
- Orientation: Vertical
- PC Tail Length: 2.90mm
- PCB Thickness - Recommended: 1.60mm
- Packaging Type: Tube
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- Plating Min - Mating: Tin
- Plating Min - Termination: Tin
- Surface Mount Compatible (SMC): No
- Temperature Range - Operating: -55°C to +105°C
- Termination Interface: Style: Through Hole
- Current - Maximum per Contact: 3A
- Voltage - Maximum: 350V
Buy the Molex Series 90147 C-Grid PCB Connector: 901471105
Discover the Molex 901471105 PCB Connector – a high-quality, 5-circuit vertical board-to-board connector with tin-plated contacts, ideal for compact electronic designs. Featuring a 2.54mm pitch, operating from -55°C to +105°C, it is UL and CSA certified and RoHS compliant. Its robust construction includes a phosphor bronze metal body and a polyester housing, providing excellent durability and reliable signal transmission. Easy to install with through-hole termination, this connector is perfect for electronics requiring dependable connectivity in tight spaces.
Buy Molex 901471105 now and experience unmatched reliability and performance with a compact, durable signal connector for electronic assemblies.
