NKK Switches YB26SKW01 Control Switch
This is an illuminated pushbutton switch designed for panel mounting. It features a short body for easy installation and reliable operation, commonly used in control panels and automation systems. The switch includes a clear lens, multiple LED color options, and compatibility with various mounting types such as bushing or snap-in. It provides a 3A @ 125/250V AC rating with high durability, IP65 sealing, and a tactile response for operators. Suitable for industrial control panels, machinery, and automation applications requiring robust and illuminated switch interfaces.
NKK Switches YB26SKW01 Control Switch Specifications:
- Electrical Capacity: 3A @ 125/250V AC; 0.4VA max @ 28V AC/DC; Resistive load
- Contact Resistance: 50 milliohms max for silver, 100 milliohms max for gold
- Insulation Resistance: 200 megohms min @ 500V DC
- Dielectric Strength: 1,000V AC for 1 minute between contacts, 1,500V AC between contacts and case
- Mechanical Life: 1,000,000 operations min for momentary, 200,000 for maintained circuits
- Operating Temperature Range: -25°C to +50°C (illuminated), -25°C to +70°C (non-illuminated)
- Panel Seal: IP65, with exterior o-ring for panel sealing
- Housing Material: UL94V-0 Polyamide, with stainless steel contact
- Mounting: Bushing or snap-in mounting, panel thickness up to 3.8mm
- Lumination: Full face or spot illumination using incandescent or LED lamps
- LED Colors: Red, amber, green, blue, white, with resistor options
- Dimensions: Approximate diameter 15 mm, depth varies by mounting type
- Standards: UL recognized, CSA certified upon request
Buy the NKK Short Body Pushbuttons – Reliable Illuminated Switches for Industrial Applications
Upgrade your control panels with the NKK Short Body Pushbutton, offering reliable illumination, IP65 sealing, and high durability. Perfect for industrial automation requiring robust, easy-to-install switches that ensure operational safety and visibility. Available with various LED color options and compatible mounting styles, this switch enhances operator interface and maintains compliance with safety standards. Shop online now to ensure dependable performance in demanding industrial environments and streamline your equipment controls with confidence.
Order your NKK Series YB Short Body Pushbutton today and give your projects the dependable, illuminated control solution they deserve.
Frequently Asked Questions
Where can I buy NKK Switches YB26SKW01?
You can click on the BUY or RFQ button to purchase YB26SKW01 from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part YB26SKW01?
You can download the YB26SKW01 datasheet or visit the NKK Switches website for support.
Who is the manufacturer of YB26SKW01?
NKK Switches
